双向可控硅 MAC4D
| 价 格： | 面议 | |
| 型号/规格： | MAC4D | |
| 品牌/商标： | SZGKT |
DESCRIPTION:
Designed for high volume, low cost, industrial and consumer applications such as motor control;
process control; temperature, light and speed control.
FEATURES:
* Small Size Surface Mount DPAK Package
* Passivated Die for Reliability and Uniformity
* Blocking Voltage to 800 V
* On−State Current Rating of 4.0 A RMS at 108°C
* High Immunity to dv/dt − 500 V/s at 125°C
* High Immunity to di/dt − 6.0 A/ms at 125°C
* Epoxy Meets UL 94 V−0 @ 0.125 in
* ESD Ratings: Human Body Model, 3B 8000 V Machine Model, C 400 V
* Pb−Free Packages are Available
MAXIMUM RATINGS (TJ = 25°C unless otherwise noted)
* VDRM ≤ 600V (MAC4DCM、MAC4DSM、MAC4DHM、MAC4DLM)
* VDRM ≤ 800V (MAC4DCN、MAC4DSN)
* ITSM ≤ 40A
* IT(RMS) ≤ 4A
* IGT ≤ 3mA (MAC4DLM)
* IGT ≤ 5mA (MAC4DHM)
* IGT ≤ 10mA (MAC4DSM、MAC4DSN)
* IGT ≤ 35mA (MAC4DCM、MAC4DCN)
* VT ： 1.6V
* VGT : 1.3V
