双向可控硅MAC8
| 价 格： | 面议 | |
| 型号/规格： | MAC8 | |
| 品牌/商标： | SZGKT |
DESCRIPTION:
Designed for industrial and consumer applications for full wave control of ac loads such as appliance controls,
heater controls, motor controls, and other power switching applications.
FEATURES:
* Blocking Voltage to 800 Volts
* On-State Current Rating of 8.0 Amperes RMS at 100°C
* Uniform Gate Trigger Currents in Three Quadrants
* High Immunity to dv/dt − 250 V/s minimum at 125°C
* Minimizes Snubber Networks for Protection
* Industry Standard TO-220AB Package
* High Commutating di/dt − 6.5 A/ms minimum at 125°C
* These Devices are Pb−Free and are RoHS Compliant
MAXIMUM RATINGS (TJ = 25°C unless otherwise noted)
* VDRM ≤ 600V (MAC8MG、MAC8SM)
* VDRM ≤ 800V (MAC8NG、MAC8SN)
* ITSM ≤ 80A
* IT(RMS) ≤ 8A
* IGT ≤ 5mA (MAC8SM,MAC8SN)
* IGT ≤ 35mA (MAC8MG,MAC8NG)
* VT ： 1.6V
* VGT : 1.5V
