双向可控硅MAC997
| 价 格： | 面议 | |
| 型号/规格： | MAC997 | |
| 品牌/商标： | SZGKT |
DESCRIPTION
Designed for use in solid state relays, MPU interface, TTL logic and any other light industrial
or consumer application. Supplied in an inexpensive TO−92 package which is readily adaptable
for use in automatic insertion equipment.
FEATURES
* One−Piece, Injection−Molded Package
* Blocking Voltage to 600 Volts
* Sensitive Gate Triggering in Four Trigger Modes (Quadrants) for all possible Combinations
of Trigger Sources, and especially for Circuits that Source Gate Drives
* All Diffused and Glassivated Junctions for Maximum Uniformity of Parameters and Reliability
* Improved Noise Immunity (dv/dt Minimum of 20 V/μsec at 110°C)
* Commutating di/dt of 1.6 Amps/msec at 110°C
* High Surge Current of 8 Amps
* Device Marking: Device Type, e.g., for MAC997A6: MAC7A6, Date Code
MAXIMUM RATINGS (TJ = 25°C unless otherwise noted)
* VDRM ≤ 600V (MAC997A6、MAC997B6)
* VDRM ≤ 800V (MAC997A8、MAC997B8)
* ITSM ≤ 8A
* IT(RMS) ≤ 0.8A
* IGT ≤ 3mA (MAC997A6,MAC997A8)
* IGT ≤ 5mA (MAC997B6,MAC997B8)
* VT ： 1.9V
* VGT : 2V
