双向可控硅 BTA206
| 价 格： | 面议 | |
| 型号/规格： | BTA206 | |
| 品牌/商标： | SZGKT |
General description
Planar passivated high commutation three quadrant triac in a SOT78 (TO-220AB) plastic
package and SOT186A (TO-220F) "full pack" plastic package intended for use in circuits
where high static and dynamic dV/dt and high dI/dt can occur. This "series CT" triac will
commutate the full RMS current at the maximum rated junction temperature (Tj = 150 °C)
without the aid of a snubber where "high junction operating temperature capability" is required.
Features and benefits
* 3Q technology for improved noise immunity
* High commutation capability with maximum false trigger immunity
* High immunity to false turn-on by dV/dt
* High junction operating temperature capability
* High voltage capability
* Planar passivated for voltage ruggedness and reliability
* Triggering in three quadrants only
Applications
* Applications subject to high temperature
* Electronic thermostats (heating and cooling)
* Motor controls for home appliances
* Rectifier-fed DC inductive loads e.g. DC motors and solenoids
Quick reference data
* VDRM ≤ 800V
* ITSM ≤ 60A
* IT(RMS) ≤ 6A
* IGT ≤ 35mA(BTA206-800CT)(BTA206X-800CT)
* IGT ≤ 10mA(BTA206-800ET)(BTA206X-800ET)
* VT : 1.3-1.6V
* VGT : 0.8-1.5V
