供应射频变压器 ADT16-6+

价 格: 面议
型号/规格:ADT16-6+
品牌/商标:Mini-Circuits
包装方式:多件包装
主要用途:精密电子仪器仪表
适用电源类别:单相
铁芯类型:E型
频率特征:工频
导线类型:铜导线

ADT16-6T+:Mini-Circuits RF射频变压器 Surface Mount RF Transformer 50Ω 0.1 to 70 MHz





Maximum Ratings:

Operating Temperature -20°C to 85°C
Storage Temperature -55°C to 100°C
RF Power 0.25W
DC Current 30mA

Permanent damage may occur if any of these limits are exceeded





Pin Connections:

PRIMARY DOT 3
PRIMARY 1
SECONDARY DOT 4
SECONDARY 6
SECONDARY CT 5
NOT USED 2





Features:

• excellent return loss, 16 dB typ. in 1 dB bandwidth
• excellent amplitude unbalance, 0.05 dB typ.
• excellent phase unbalance, 1 deg. typ.in 1 dB bandwidth
• aqueous washable
• protected under US patent 6,133,525





Applications:

• impedance matching
• baluns

深圳市浩时健电子有限公司
公司信息未核实
  • 所属城市:广东 深圳
  • [联系时请说明来自维库仪器仪表网]
  • 联系人: 李小姐
  • 电话:0755-83996702/82861853/83017431
  • 传真:0755-83017431
  • 手机:13760397503
  • QQ :QQ:296326833
