供应奇美筆記本液晶屏13.3寸N133I6-L0A(图)
| 价 格： | 80.00 | |
| 品牌/商标： | 奇美cmo | |
| 型号/规格： | N133I6-L0A | |
| 尺寸： | 13.3（寸） | |
| 颜色： | 262k | |
| 像素点阵： | 1280x800 | |
| 接口： | lvds | |
| 亮度： | 300 | |
| 对比度： | 300：1 | |
| 连接方式： | TAB | |
| 种类： | LCD液晶屏 |
奇美电子以优越前瞻技术和设计能力，提供轻薄化、广视角、省电、高亮度的全系列宽屏幕笔记本电脑液晶显示器，为信息产品带来更多方便性。产品涵括8.9吋至18.4吋宽屏幕笔记本电脑液晶显示器，薄型化产品种类齐全，满足多功能应用方面的可携式娱乐显示。
| Model Name | N133I6-L0A |
|---|---|
| Panel Size | 13.3" Wide |
| Technology | TN |
| Resolution | 1280x800 |
| Pixel Pitch(mm) | 0.2235 |
| Active Area(mm) | 286.08x178.8 |
| Outline(mm) | 304.75x203.2x3.85 |
| Luminance(nits) | 300 |
| View Angle (U/D/R/L) | 20/45/45/45 |
| Contrast Ratio | 300:1 |
| Support Color | 262K |
| Power Consumption (w) | 4.8 |
| Response Time(ms) | 12 |
| Weight (g) | 245 max |
| Electrical Interface | LVDS |
| Mass Production | MP |
| Remark | LED, Ultra Slim, Super Light, 16:10 |
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 黄熙承
- 电话：0755-83954981
- 传真：0755-83954981
- 手机：
- QQ ：
香港交货奇美液晶屏22w液晶屏M220Z1-L03
信息内容：奇美电子以优越前瞻技术和设计能力，提供薄型化、宽广视角、快速反应、高分辨率、高对比、高色彩饱和度全系列多功能应用的宽屏幕桌上型液晶显示器：产品包括16:10和16:9宽屏幕面板。因应信息产品个人化、娱乐化趋势，奇美电子业界制定了16:10商用和16:9娱乐用宽屏幕面板规格，领导了宽屏幕市场潮流。Model NameM220Z1-L03Panel Size22" Wide (16:10)TechnologyTNResolution1680x1050Pixel Pitch(mm)0.282Active Area(mm)473.76x296.1Outline(mm)493.7x320.1x16.5Luminance(nits)300View Angle (U/D/R/L)80/80/85/85Contrast Ratio1000:1Support Color16.7MResponse Time(ms)5Weight (g)2550Electrical InterfaceLVDSMass ProductionMPRemarkColor Gamut (72% NTSC)"
香港供應京東方BOE7寸IPS液晶屏1024x600 HV070WS1-100
信息内容：HV070WS1-100 is a color active matrix TFT LCD module using amorphous silicon TFT's(Thin Film Transistors) as an active switching devices. This module has a 7.01 inchdiagonally measured active area with WSVGA resolutions (1024 horizontal by 600 verticalpixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged invertical Stripe and this module can display 16.7M colors. The TFT-LCD panel used for thismodule is a low reflection and higher color type.? Thin and Light Weight? 3.7 V Logic Power & Back-light power Supply? 1 Channel LVDS Interface? SMD LED (20EA) Array (Bottom Side/Horizontal Direction)? 16.7M Colors? Data Enable Signal Mode? Green Product (RoHS) & Halogen free Active area 153.6(H) ×90.0(V) mmNumber of pixels 1024(H) ×600(V) pixelsPixel pitch 0.15(H) ×0.15(V) mmPixel arrangement RGB Vertical StripeDisplay colors 16.7M colorsDisplay mode Normally BlackOutline dimension 164.05?0.2(H)×99.96?0.15(V)×2.35 ?0.15(D) mm ...
