HV070WS1-100 is a color active matrix TFT LCD module using amorphous silicon TFT's
(Thin Film Transistors) as an active switching devices. This module has a 7.01 inch
diagonally measured active area with WSVGA resolutions (1024 horizontal by 600 vertical
pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in
vertical Stripe and this module can display 16.7M colors. The TFT-LCD panel used for this
module is a low reflection and higher color type.

? Thin and Light Weight
? 3.7 V Logic Power & Back-light power Supply
? 1 Channel LVDS Interface
? SMD LED (20EA) Array (Bottom Side/Horizontal Direction)
? 16.7M Colors
? Data Enable Signal Mode
? Green Product (RoHS) & Halogen free

Active area 153.6(H) ×90.0(V) mm
Number of pixels 1024(H) ×600(V) pixels
Pixel pitch 0.15(H) ×0.15(V) mm
Pixel arrangement RGB Vertical Stripe
Display colors 16.7M colors
Display mode Normally Black
Outline dimension 164.05?0.2(H)×99.96?0.15(V)×2.35 ?0.15(D) mm Note 1
(CTF)
Back-light Bottom edge side, 20-LEDs type
Note 1 : at without component

CN1 Interface Connector (FF12-31A-R12BN, Manufactured by DDK)
Pin No. Symbol Function
1 VDD_3.7
2 VDD_3.7
3 VDD_3.7
4 VDD_3.7
5 VDD_3.7
6 VDD_3.7
7 VDD_3.7
8 NC Non Connection

9 NC Non Connection
10 LDO_EN LDO enable for driver IC
11 COG3_1 GROUND
12 GND GROUND
13 RIN0- LVDS Negative data signal (-)
14 RIN0 LVDS Negative data signal ( )

15 GND GROUND
16 RIN1- LVDS Negative data signal (-)
17 RIN1 LVDS Positive data signal ( )
18 GND GROUND
19 RIN2- LVDS Negative data signal (-)
20 RIN2 LVDS Positive data signal

21 GND GROUND
22 LVDS_CLK- LVDS Negative CLK signal (-)
<Table 5, Electrical Interface Connection >
Power supply : V_BAT
(4.2V~3.2V)
23 LVDS_CLK LVDS Positive CLK signal ( )
24 GND GROUND
25 RIN3- LVDS Negative data signal (-)
26 RIN3 LVDS Positive data signal ( )
27 GND GROUND
28 LED_EN LED enable (PWM)
29 GND GROUND
30 GND GROUND
31 COG1 BIST
(-)
