快恢复二极管 1N4937
| 价 格： | 130.00 | |
| 是否提供加工定制： | 是 | |
| 产品类型： | 快恢复二极管 | |
| 是否进口： | 否 | |
| 品牌/商标： | PN | |
| 型号/规格： | 1N4937 1N4935 1N4933 | |
| 材料： | 硅(Si) | |
| 主要参数： | IF=1.0 VB大于600V | |
| 用途： | 主要应用于开关电源、PWM脉宽调制器、变频器等电子电路中，作为高频整流二极管、续流二极管或阻尼二极管使用 |
| SYMBOL | 1N4933 | 1N4934 | 1N4935 | 1N4936 | 1N4937 | UNITS |
峰值反向电压 MaximumCurrent PeakReverse Voltage | VRRM | 50 | 100 | 200 | 400 | 600 | Volts |
反向有效电压 Maximum RMS Voltage | VRMS | 35 | 70 | 140 | 280 | 420 | Volts |
直流阻断电压 Maximum DC Blocking Voltage | VDC | 50 | 100 | 200 | 400 | 600 | Volts |
正向平均整流电流TA=50℃ Maximum Average Forward Rectified Current | I(AV) | 1.0 | Amps | ||||
正向峰值浪涌电流 Peak Forward Surge Current Single Sine-wave on Rated Load (JEDEC Method) | IFSM | 30.0 | Amps | ||||
1.0A直流电时正向瞬间电压降 Maximum Instantaneous Forward Voltage Drop at 1.0A DC | VF | 1.3 | Volts | ||||
反向漏电流 Maximum DC Reverse Current TA=25℃ at Rated DC Blocking Voltage TA=100℃ | IR | 5.0 100.0 | uA | ||||
反向恢复时间 Typical Reverse Recovery Time (NOTE 1) | Trr | 200 | nS | ||||
典型结节电容 Typical Junction Capacitance (NOTE 2) | CJ | 15 | pF | ||||
工作温度存储温度 OperatingANDStorageTemperature Range | TJ/TSTG | -55 to +125/-65 to +150 | ℃ | ||||
- 所属城市：湖北
- [联系时请说明来自维库仪器仪表网]
- 联系人： 周慧
- 电话：8607124767777
- 传真：8607124777999
- 手机：
- QQ ：
FRD 快恢复二极管 RGL34M DO-213AA
信息内容：大量供应快恢复二极管（FRD）: 型号:RGL34M RGL34K RGL34J RGL34D RGL34B 系列 SYMBOLRGLUNITS34A34B34D34G34J34K34M峰值反向电压MaximumCurrent PeakReverse VoltageVRRM501002004006008001000Volts反向有效电压Maximum RMS VoltageVRMS3570140280420560700Volts直流阻断电压Maximum DC Blocking VoltageVDC501002004006008001000Volts正向平均整流电流TT=60℃Maximum Average Forward Rectified CurrentI(AV)0.5Amps正向峰值浪涌电流Peak Forward Surge Current Single Sine-wave on Rated Load (JEDEC Method)IFSM25Amps0.5A直流电时正向瞬间电压降Maximum Instantaneous Forward Voltage Drop at 0.5A DCVF1.3Volts反向漏电流Maximum DC Reverse Current TA=25℃at Rated DC Blocking Voltage TA=125℃IR5.0100.0µA逆向恢复时间Maximum Reverse Recovery Time(NOTE 1)Trr150250500nS典型结电容Typical Junction Capacitance(NOTE 2)CJ15pF工作温度与存储温度OperatingANDStorageTemperature RangeTJ/TSTG-55 to +150℃
MELF EGL341J 快恢复二极管 DO-213AB
信息内容：SYMBOLEGLUNITS341A341B341C341D341F341G341J峰值反向电压MaximumCurrent PeakReverse VoltageVRRM50100150200300400600Volts反向有效电压Maximum RMS VoltageVRMS3570100140210280420Volts直流阻断电压Maximum DC Blocking VoltageVDC50100150200300400600Volts正向平均整流电流TT=60℃Maximum Average Forward Rectified CurrentI(AV)1.0Amps正向峰值浪涌电流Peak Forward Surge Current Single Sine-wave on Rated Load (JEDEC Method)IFSM30Amps1.0A直流电时正向瞬间电压降Maximum Instantaneous Forward Voltage Drop at1.0ADCVF1.051.31.75Volts反向漏电流Maximum DC Reverse Current TA=25℃at Rated DC Blocking Voltage TA=125℃IR5.0100.0µA逆向恢复时间Maximum Reverse Recovery Time(NOTE 1)Trr35nS典型结电容Typical Junction Capacitance(NOTE 2)CJ1575pF工作温度与存储温度OperatingANDStorageTemperature RangeTJ/TSTG-65 to +150℃ 大量供应快恢复二极管（FRD）EGL341J EGL341G EGL341F EGL341D EGL341C EGL341B EGL341A DO-213AB 封装。"
