FRD 快恢复二极管 RGL34M DO-213AA
| 价 格： | 150.00 | |
| 是否提供加工定制： | 是 | |
| 产品类型： | 快恢复二极管 | |
| 是否进口： | 否 | |
| 品牌/商标： | PN | |
| 型号/规格： | DO-213AA | |
| 材料： | 硅(Si) | |
| 主要参数： | IF=0.5A VB大于1000V | |
| 用途： | 应用于开关电源、PWM脉宽调制器、变频器等电子电路中，作为高频整流二极管、续流二极管或阻尼二极管使用 |
大量供应快恢复二极管（FRD）:
型号:RGL34M RGL34K RGL34J RGL34D RGL34B 系列
| SYMBOL | RGL | UNITS | ||||||||
34A | 34B | 34D | 34G | 34J | 34K | 34M | |||||
峰值反向电压 MaximumCurrent PeakReverse Voltage | VRRM | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | Volts | ||
反向有效电压 Maximum RMS Voltage | VRMS | 35 | 70 | 140 | 280 | 420 | 560 | 700 | Volts | ||
直流阻断电压 Maximum DC Blocking Voltage | VDC | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | Volts | ||
正向平均整流电流TT=60℃ Maximum Average Forward Rectified Current | I(AV) | 0.5 | Amps | ||||||||
正向峰值浪涌电流 Peak Forward Surge Current Single Sine-wave on Rated Load (JEDEC Method) | IFSM | 25 | Amps | ||||||||
0.5A直流电时正向瞬间电压降 Maximum Instantaneous Forward Voltage Drop at 0.5A DC | VF | 1.3 | Volts | ||||||||
反向漏电流 Maximum DC Reverse Current TA=25℃ at Rated DC Blocking Voltage TA=125℃ | IR | 5.0 100.0 | µA | ||||||||
逆向恢复时间 Maximum Reverse Recovery Time(NOTE 1) | Trr | 150 | 250 | 500 | nS | ||||||
典型结电容 Typical Junction Capacitance(NOTE 2) | CJ | 15 | pF | ||||||||
工作温度与存储温度 OperatingANDStorageTemperature Range | TJ/TSTG | -55 to +150 | ℃ | ||||||||
