MELF EGL341J 快恢复二极管 DO-213AB
| 价 格： | 258.00 | |
| 是否提供加工定制： | 是 | |
| 产品类型： | 快恢复二极管 | |
| 是否进口： | 否 | |
| 品牌/商标： | PN | |
| 型号/规格： | EGL341J EGL341G EGL341D EGL341A | |
| 材料： | 硅(Si) | |
| 主要参数： | IF=1.0A 反向击穿电压大于600V | |
| 用途： | 主要应用于开关电源、PWM脉宽调制器、变频器等电子电路中，作为高频整流二极管、续流二极管或阻尼二极管使用。 |
| SYMBOL | EGL | UNITS | |||||||||
341A | 341B | 341C | 341D | 341F | 341G | 341J | ||||||
峰值反向电压 MaximumCurrent PeakReverse Voltage | VRRM | 50 | 100 | 150 | 200 | 300 | 400 | 600 | Volts | |||
反向有效电压 Maximum RMS Voltage | VRMS | 35 | 70 | 100 | 140 | 210 | 280 | 420 | Volts | |||
直流阻断电压 Maximum DC Blocking Voltage | VDC | 50 | 100 | 150 | 200 | 300 | 400 | 600 | Volts | |||
正向平均整流电流TT=60℃ Maximum Average Forward Rectified Current | I(AV) | 1.0 | Amps | |||||||||
正向峰值浪涌电流 Peak Forward Surge Current Single Sine-wave on Rated Load (JEDEC Method) | IFSM | 30 | Amps | |||||||||
1.0A直流电时正向瞬间电压降 Maximum Instantaneous Forward Voltage Drop at1.0ADC | VF | 1.05 | 1.3 | 1.75 | Volts | |||||||
反向漏电流 Maximum DC Reverse Current TA=25℃ at Rated DC Blocking Voltage TA=125℃ | IR | 5.0 100.0 | µA | |||||||||
逆向恢复时间 Maximum Reverse Recovery Time(NOTE 1) | Trr | 35 | nS | |||||||||
典型结电容 Typical Junction Capacitance(NOTE 2) | CJ | 15 | 75 | pF | ||||||||
工作温度与存储温度 OperatingANDStorageTemperature Range | TJ/TSTG | -65 to +150 | ℃ | |||||||||
大量供应快恢复二极管（FRD）EGL341J EGL341G EGL341F EGL341D EGL341C EGL341B EGL341A DO-213AB 封装。
