ARL2512F ARSL2512F
| 价 格： | 1.00 | |
| 是否提供加工定制： | 是 | |
| 产品类型： | 整流管 | |
| 是否进口： | 否 | |
| 品牌/商标： | PN | |
| 型号/规格： | ARL2512F ARSL2512F | |
| 材料： | 硅(Si) | |
| 主要参数： | IF正向直流电流25A 反向击穿电压大于1200V | |
| 用途： | 高压整流二极管 |
|
SYMBOLS | ARL2505F ARSL2505F | ARL251F ARSL251F | ARL252F ARSL252F | ARL254F ARSL254F | ARL256 ARSL256F | ARL258F ARSL258F | ARL2510F ARSL2510F | ARL2512F ARSL2512F |
UNITS |
峰值反向電壓 Maximum recurrent reverse voltage |
VRRM |
50 |
100 |
200 |
400 |
600 |
800 |
1000 |
1200 |
Volts |
RMS輸入電壓 Maximum RMS voltage |
VRMS |
35 |
70 |
140 |
280 |
420 |
560 |
700 |
840 |
Volts |
直流阻斷電壓 Maximum DC blocking voltage |
VDC |
50 |
100 |
200 |
400 |
600 |
800 |
1000 |
1200 |
Volts |
平均正向整流電流 Maximum average forward rectified current at Tc=60℃ |
I(AV) |
25 |
Amps | |||||||
正向峰值浪涌電流 Peak forward surge current single sine-wave on rated load (JEDEC Method) |
IFSM |
300 |
Amps | |||||||
25A時正向瞬間電壓降 Maximum instantaneous forward voltage drop at6A,Tj=25℃ |
VF |
1.1 |
Volts | |||||||
反向漏電流 Maximum DC reverse current TA=25℃ at rated DC blocking voltage TA=100℃ |
IR |
5.0 100.0 |
μA | |||||||
工作溫度和存儲溫度 Operating and Storage Temperature Range | TJ TSTG |
-55 TO +150 | ℃ | |||||||
"
