SM 4937 快恢复二极管 DO-213AB
| 价 格： | 149.00 | |
| 是否提供加工定制： | 是 | |
| 产品类型： | 快恢复二极管 | |
| 是否进口： | 否 | |
| 品牌/商标： | PN | |
| 型号/规格： | SM 4937 SM4936 SM4935 | |
| 材料： | 硅(Si) | |
| 主要参数： | IF=1.0A VB反向击穿电压大于600V | |
| 用途： | 应用于开关电源、PWM脉宽调制器、变频器等电子电路中，作为高频整流二极管、续流二极管或阻尼二极管使用 |
大量供应快恢复二极管（FRD）:
型号:SM4937 SM4936 SM4935 SM4934 SM4933 系列
| SYMBOL | SM 4933 | SM 4934 | SM 4935 | SM 4936 | SM 4937 | UNITS |
峰值反向电压 Maximum current Peak Reverse Voltage | VRRM | 50 | 100 | 200 | 400 | 600 | Volts |
反向有效电流 Maximum RMS Voltage | VRMS | 35 | 70 | 140 | 280 | 420 | Volts |
直流阻断电压 Maximum DC Blocking Voltage | VDC | 50 | 100 | 200 | 400 | 600 | Volts |
正向平均整流电流TT=55℃ Maximum Average Forward Rectified Current | I(AV) | 1.0 | Amps | ||||
正向峰值浪涌电流 Peak Forward Surge Current, 8.3 ms Single Half Sine-wave Superimposed on Rated Load (JEDEC Method) | IFSM | 30 | Amps | ||||
1.0A直流电时正向瞬间电压降 Maximum Instantaneous Forward Voltage @ 1.0A | VF | 1.3 | Volts | ||||
反向漏电流 Maximum DC Reverse Current @ TA=25℃ at Rated DC Blocking Voltage @ TA=125℃ | IR | 5.0 100.0 | uA | ||||
逆向恢复时间 Maximum Reverse Recovery Time ( Note 1 ) | Trr | 200 | nS | ||||
典型结电容 Typical Junction Capacitance ( Note 2 ) | CJ | 15 | pF | ||||
工作温度存储温度 Operating AND Storage Temperature Range | TJ/TSTG | -55 to +150 | ℃ | ||||
"
