肖特基二极管 SR830 SR860 TO-220A
| 价 格： | 0.90 | |
| 是否提供加工定制： | 是 | |
| 产品类型： | 肖特基管 | |
| 是否进口： | 否 | |
| 品牌/商标： | PN | |
| 型号/规格： | SR830 SR840 SR850 SR860 | |
| 材料： | 硅(Si) | |
| 主要参数： | IF=8.0A VB大于60V | |
| 用途： | 用作高频、低压、大电流整流二极管（比如开关电源次极整流二极管），续流二极管、保护二极管，也有用在微波通信等电路中作整流二极管、小信号检波二极管使用 |
| SYMBOL | SR830 | SR835 | SR840 | SR845 | SR850 | SR860 | UNITS | ||
峰值反向电压 MaximumCurrent PeakReverse Voltage | VRRM | 30 | 35 | 40 | 45 | 50 | 60 | Volts | ||
反向有效电压 Maximum RMS Voltage | VRMS | 21 | 25 | 28 | 32 | 35 | 42 | Volts | ||
直流阻断电压 Maximum DC Blocking Voltage | VDC | 30 | 35 | 40 | 45 | 50 | 60 | Volts | ||
正向平均整流电流 Maximum Average Forward Rectified Current
| I(AV) | 8.0 | Amps | |||||||
正向峰值浪涌电流 Peak Forward Surge Current 8.3ms Single Sine-wave on Rated Load (JEDEC Method) | IFSM | 200.0 | Amps | |||||||
8.0A直流电时正向瞬间电压降 Maximum Instantaneous Forward Voltage Drop at 8.0A DC | VF | 0.55 | 0.75 | Volts | ||||||
反向漏电流 Maximum DC Reverse Current TA=25℃ at Rated DC Blocking Voltage TA=100℃ | IR | 0.5 10.0 | mA | |||||||
典型热阻 Typical Thermal Resistance (NOTE 1) | RθJC | 2.5 | ℃/W | |||||||
典型结电容 Typical Junction Capacitance (NOTE 2) | CJ | 700 | 450 | pF | ||||||
工作温度存储温度 Operating AND Storage Temperature Range | TJ/TSTG | -55 to +125/-65 to +150 | ℃ | |||||||
- 所属城市：湖北
- [联系时请说明来自维库仪器仪表网]
- 联系人： 周慧
- 电话：8607124767777
- 传真：8607124777999
- 手机：
- QQ ：
SM 4937 快恢复二极管 DO-213AB
信息内容：大量供应快恢复二极管（FRD）: 型号:SM4937 SM4936 SM4935 SM4934 SM4933 系列 SYMBOLSM4933SM4934SM4935SM4936SM4937UNITS峰值反向电压Maximum current Peak Reverse VoltageVRRM50100200400600Volts反向有效电流Maximum RMS VoltageVRMS3570140280420Volts直流阻断电压Maximum DC Blocking VoltageVDC50100200400600Volts正向平均整流电流TT=55℃Maximum Average Forward Rectified CurrentI(AV)1.0Amps正向峰值浪涌电流Peak Forward Surge Current, 8.3 ms Single Half Sine-wave Superimposed on Rated Load (JEDEC Method)IFSM30Amps1.0A直流电时正向瞬间电压降Maximum Instantaneous Forward Voltage @ 1.0AVF1.3Volts反向漏电流Maximum DC Reverse Current @ TA=25℃at Rated DC Blocking Voltage @ TA=125℃IR5.0100.0uA逆向恢复时间Maximum Reverse Recovery Time ( Note 1 )Trr200nS典型结电容Typical Junction Capacitance ( Note 2 )CJ15pF工作温度存储温度Operating AND Storage Temperature RangeTJ/TSTG-55 to +150℃ "
ARL2512F ARSL2512F
信息内容：SYMBOLSARL2505FARSL2505FARL251FARSL251FARL252FARSL252FARL254FARSL254FARL256ARSL256FARL258FARSL258FARL2510FARSL2510FARL2512FARSL2512F UNITS峰值反向電壓Maximum recurrent reverse voltage VRRM 50 100 200 400 600 800 1000 1200 VoltsRMS輸入電壓Maximum RMS voltage VRMS 35 70 140 280 420 560 700 840 Volts直流阻斷電壓Maximum DC blocking voltage VDC 50 100 200 400 600 800 1000 1200 Volts平均正向整流電流Maximum average forward rectified current atTc=60℃ I(AV) 25 Amps正向峰值浪涌電流Peak forward surge current single sine-wave on rated load (JEDEC Method) IFSM 300 Amps25A時正向瞬間電壓降Maximum instantaneous forward voltage drop at6A,Tj=25℃ VF 1.1 Volts反向漏電流Maximum DC reverse current TA=25℃at rated DC blocking voltage TA=100℃ IR 5.0100.0 μA工作溫度和存儲溫度Operating and Storage Temperature RangeTJTSTG -55 TO +150℃ "
