供应中华液晶屏CLAA080LA0ACW
| 价 格： | 面议 | |
| 型号/规格： | CLAA080LA0ACW | |
| 品牌/商标： | 中华映管 |
CLAA080LA0ACW is 20.15cm (8") color TFT-LCD (Thin Film Transistor Liquid Crystal
Display) module composed of LCD panel, driver ICs , control circuit and LED backlight.
The 20.15cm (8") screen produces 800×RGB×480 resolution image. By applying 8 bits
digital data, 16M color images are displayed.
General specification are summarized in the following table:
【Note
*1) Pixel arrangement：
ITEM SPECIFICATION
Display Area (mm) 172.8(H) × 103.68(V)
Number of Pixels 800(H) × 3(RGB)× 480(V) (Note*1)
Pixel Pitch (mm) 0.216(H) × 0.216 (V)
Color Pixel Arrangement RGB vertical stripe (Note*1)
Display Mode Normally white,TN
Number of color 16M
Viewing Direction 6 o'clock
Response Time (Tr+Tf) 25 ms (typ)
Brightness (cd/㎡) 250 nit (typ)
Viewing Angle (CR≧10) 140 degree (Horizontal)
120 degree (Vertical)
Electrical Interface TTL
Power Consumption (W) 1.85 (typ)
Outline Dimension (mm) 192.8(W) × 116.9(H) × 6.4(D)
module weight (g) 170 (typ)
Backlight LED
Surface Treatment Anti-Glare，Surface hardness: 3Ｈ
- 所属城市：广东 韶关
- [联系时请说明来自维库仪器仪表网]
- 联系人： 罗小姐
- 电话：0755-27821716
- 传真：-
- 手机：18926752642
- QQ ：
