供应中华液晶屏CLAA102NA01CW
| 价 格： | 面议 | |
| 型号/规格： | CLAA102NA01CW | |
| 品牌/商标： | 中华映管 |
CLAA102NA01CW is 10.2” color TFT-LCD (Thin Film Transistor Liquid Crystal Display)
module composed of LCD panel, driver ICs ,control circuit and backlight. By applying
1024×600 images are displayed on the 10.2” diagonal screen. Display 262K colors by 6
Bit R.G.B signal input.
General specification are summarized in the following table:
ITEM SPECIFICATION
Display Area (mm) 222.72(H) x 130.5(V) (10.2-inch diagonal)
Number of Pixels 1024(H) × 3(RGB) × 600(V)
Pixel Pitch (mm) 0.2175 (H) × 0.2175 (V)
Color Pixel Arrangement RGB vertical stripe
Display Mode Normally white, TN
Number of Colors 262,144
Optimum Viewing Angle 6 o’clock
Brightness (cd/m^2) 400nit(typ)
Response Time (ms) 25ms (typ)
Viewing Angle 14101 0d edgergeree e(H (oVreizrtoicnatal)l .)
Power Consumption (with BLU) 6.6W(typ)
Interface connection LVDS
Module Size (mm) (w/o PWB) 235(W) ×145.8(H) × 5.9(D)
Module Size (mm) (with PET) 235(W) ×145.8(H) × 7.86(D)
Module Weight (g) 385g (Max)
Backlight Unit CCFL
Surface Treatment Anti-Glare
- 所属城市：广东 韶关
- [联系时请说明来自维库仪器仪表网]
- 联系人： 罗小姐
- 电话：0755-27821716
- 传真：-
- 手机：18926752642
- QQ ：
供应中华液晶屏CLAB070JA05CW
信息内容：CLAB070JA05CW is 7.0" color TFT-LCD (Thin Film Transistor Liquid Crystal Display)OLB module (finish outer lead bonding) composed of LCD panel and driver ICs (the backlightis not included in this OLB module).The 7.0" (17.67cm) screen produces 480(*3)X234 WQVGA resolution image. By applyingR.G.B. input signal, full color images are displayed.General specifications are summarized in the following table:ITEM ECIFICATIONDisplay Area (mm) 154.08 (H) × 86.58 (V)Number of Pixels 480(H) × 3(RGB)× 234(V)Display Mode Normally white,TNNumber of color Full colorViewing Direction 6 o'clockPanel Transmittance (%) 8.3 (TYP.)Power Consumption(W) Outline Dimension(mm) 165.2(W) × 95.5(H) × 1.7(D) (exclude FPC)Surface Treatment Anti-Glare
供应中华液晶屏CLAA080LA0ACW
信息内容：CLAA080LA0ACW is 20.15cm (8") color TFT-LCD (Thin Film Transistor Liquid CrystalDisplay) module composed of LCD panel, driver ICs , control circuit and LED backlight.The 20.15cm (8") screen produces 800×RGB×480 resolution image. By applying 8 bitsdigital data, 16M color images are displayed.General specification are summarized in the following table:【Note*1) Pixel arrangement：ITEM SPECIFICATIONDisplay Area (mm) 172.8(H) × 103.68(V)Number of Pixels 800(H) × 3(RGB)× 480(V) (Note*1)Pixel Pitch (mm) 0.216(H) × 0.216 (V)Color Pixel Arrangement RGB vertical stripe (Note*1)Display Mode Normally white,TNNumber of color 16MViewing Direction 6 o'clockResponse Time (Tr+Tf) 25 ms (typ)Brightness (cd/㎡) 250 nit (typ)Viewing Angle (CR≧10) 140 degree (Horizontal)120 degree (Vertical)Electrical Interface TTLPower Consumption (W) 1.85 (typ)Outline Dimension (mm) 192.8(W) × 116.9(H) × 6.4(D)module weight (g) 170 (typ)Backlight LEDSurface Treatment Anti-Glare，Surface hardness: 3Ｈ
