供应LMD18200电机驱动IC 3A,55V,H桥

价格：		面议
型号/规格：		LMD18200T
品牌/商标：		NS

详细介绍
企业详情

Features

Delivers up to 3A continuous output

Operates at supply voltages up to 55V

Low R_DS(ON) typically 0.33Ω per switch at 3A

TTL and CMOS compatible inputs

No “shoot-through” current

Thermal warning flag output at 145°C

Thermal shutdown (outputs off) at 170°C

Internal clamp diodes

Shorted load protection

Internal charge pump with external bootstrap capability

Description

The LMD18200 is a 3A H-Bridge designed for motion control applications. The device is built using a multi-technology process which combines bipolar and CMOS control circuitry with DMOS power devices on the same monolithic structure. Ideal for driving DC and stepper motors; the LMD18200 accommodates peak output currents up to 6A. An innovative circuit which facilitates low-loss sensing of the output current has been implemented.

Applications

DC and stepper motor drives

Position and velocity servomechanisms

Factory automation robots

Numerically controlled machinery

Computer printers and plotters
