| 品牌 | Computar | 型号 | M7528-MP |
f=75mm F/2.8
ｆor 2/3 te Megapixel Cameras
C-Mount
Model No. | M7528-MP | Effective Lens Aperture | Front | φ24.8mm | |||
Focal Length | 75mm | Rear | φ13.6mm | ||||
Max. Aperture Ratio | 1:2.8 | Distortion | 2/3 te | -0.43%(y=5.5) | |||
Max. Image Format | 8.8mmx 6.6mm(φ11mm) | 1/2 te | -0.22%(y=4.0) | ||||
Operation Range | Iris | F2.8‐ F16C | Back Focal Length | 21.5mm | |||
Focus | 0.3m‐ Inf. （※） | Flange Back Length | 17.526mm | ||||
Control | Iris | Manual | Mount | C-Mount | |||
Focus | Manual | Filter Size | M30.5 P=0.5mm | ||||
Object Dimension at M.O.D | 2/3 te | 4.1cmx 3.1cm | Dimensions | φ35mm x 57.75mm | |||
1/2 te | 3cmx 2.2cm | Weight | 113g | ||||
Angle of View | D | 2/3 te | 8.5° | 1/2 te | 6.2° |
|
|
H | 6.8° | 5° |
| ||||
V | 5.1° | 3.7° |
| ||||
Operating Temperature | -10℃‐ +50℃ | ||||||
(※）Factory Setting is 0.3 - 1.2m. Focus can be adjusted to infinity by removing "Focus Limit Screw"
M.O.D : Minimum Object Distance
Dimensions
