供应场效应管DMOS管CS730A8H
| 价 格： | 1.00 | |
| 型号/规格： | CS730A8H | |
| 品牌/商标： | 华晶 | |
| 封装形式： | TO-220 | |
| 环保类别： | 无铅环保型 | |
| 安装方式： | 直插式 | |
| 包装方式： | 管装 | |
| 功率特征： | 中功率 |
6A 75V TO-220AB MOSFET
应用领域：电子镇流器，车载逆变器，非隔离式的LED驱动
General Description：
VDSS
400
V
ID
6
A
PD(TC=25℃)
75
W
RDS(ON)
0.88
Ω
CS730A8H, the silicon N-channel Enhanced VDMOSFETs, is obtained by the self-aligned planar Technology which reduce the conduction loss, improve switching performance and enhance the avalanche energy. The transistor can be used in various power switching circuit for system miniaturization and higher efficiency. The package form is TO-220AB, which accords with the RoHS standard.
Features：
Fast Switching
Low ON Resistance(Rdson≤1Ω)
Low Gate Charge (Typical Data:17nC)
Low Reverse transfer capacitances(Typical:8.3pF)
100% Single Pulse avalanche energy Test
