三极管D882
| 价 格： | 面议 | |
| 型号/规格： | D882 | |
| 品牌/商标： | SZGKT | |
| 封装形式： | TO-220 | |
| 环保类别： | 无铅环保型 | |
| 安装方式： | 直插式 | |
| 包装方式： | 单件包装 |
FEATURES:
Power dissipation
MAXIMUM RATINGS (TA=25℃ unless otherwise noted) :
Symbol
Parameter
Value
Units
VCBO
Collector-Base Voltage
40
V
VCEO
Collector-Emitter Voltage
30
V
VEBO
Emitter-Base Voltage
6
V
Ic
Collector Current -Continuous
1.25
A
Tj
Junction Temperature
150
℃
Tstg
Storage TemperatureRange
-55~150
℃
ELECTRICAL CHARACTERISTICS (Tamb=25℃ unless otherwise specified):
Symbol
Test conditions
MIN
TYP
MAX
Unit
V(BR)CBO
Ic=100uA, IE=0
40
V
V(BR)CEO
IC= 10mA, IB=0
30
V
V(BR)EBO
IE= 100uA, IC=0
5
V
ICBO
VCB=40V, IE=0
1
uA
ICEO
ICE=30V, IE=0
10
uA
IEBO
VEB=6V, IC=0
1
uA
hFE
VCE= 2V, IC= 1A
60
400
VCE(sat)
IC=2A, IB=0.2A
0.5
V
VBE(sat)
Ic= 2V, Ib=0.2A
1.5
V
fT
VCE=5V , IC=0.1A
f =10MHz
90
MHz
