双向可控硅BTA420
| 价 格： | 面议 | |
| 型号/规格： | BTA420 | |
| 品牌/商标： | SZGKT |
General description
Planar passivated high commutation three quadrant triac in a SOT78 (TO-220AB) plastic
package and a SOT186A (TO-220F) "full pack" plastic package intended for use in circuits
where high static and dynamic dV/dt and high dI/dt can occur. This "series BT" triac will
commutate the full RMS current at the maximum rated junction temperature (Tj(max) =
150 °C) without the aid of a snubber. It is used in applications where "high junction operating
temperature capability" is required.
Features and benefits
* 3Q technology for improved noise immunity
* High commutation capability with maximum false trigger immunity
* High immunity to false turn-on by dV/dt
* High junction operating temperature capability
* High voltage capability
* Least sensitive gate for highest noise immunity
* Planar passivated for voltage ruggedness and reliability
* Triggering in three quadrants only
Applications
* Applications subject to high temperature
* Heating controls
* High power motor control
* High power switching
Quick reference data
