!!!销售MS8604A 收回MS8604A 维修MS8604A频谱分析仪  双节底价MS8604A 出击MS8604A ,你HOLD的住吗？ -------------------------------------- --- dzsc/19/4141/19414178.jpg


★100Hz~8.5GHz ★由单一系统评估主发射机功能 ★与NADC,PDC,PHS,数字MCA, GSM, DCS1800(PCN), CT2, DECT,WCPE,PACS,RCR  STD-39 TETRA系统及GMSK和π/4 DQPSK通用测量软件相兼容; ★高速测量(调制精度测量小于1s) ★输入共10W(内部有用于高功率测量的20dB衰减器及功率计



技术指标

General Frequency range 100Hz to 8.5GHz  Maz.input level (continuous wave average power) +40dBm(10W)  Reference oscillator Frequency:10MHz Starting characteristics:≤5×0.00000001/day(option:≤2×0.00000001/day after30 min.warm-up) *After 10min.of warm-up,compared to the frequency after 24-hour warm-up Aging rate:≤2×0.00000001/day(option:≤5×0.000000001/year) *Compared to the frequency after 24-hour warm-up Temperature characteristics:5×0.00000001/day(option:3×0.00000001/day) *0to 50℃,relative to the frequency at 25℃  Spectrum anallyzer Frequency Setting range:100Hz to 8.5GHz(resolution:1Hz),0to 2GHz(freq.band:0),1.7to7.5GHz(freq.band:1-),6.5to 8.5GHz(freq.band:1+) Preselector range:1.7to 8.5GHz (bands:1-/1+) Display accuracy:±(display freq.×reference freq.accuracy+span×span accuracy) Span Setting range:0Hz,100Hz to 8.5GHz Accuracy: ±2.5%(span≥1kHz),±5%(100Hz≤span<1kHz) RBW Setting range:10Hz to 3MHz(3dB),1-3serqence Accuracy:±20% Selectivity(60/3dB);≤15:1(100kHz to 3MHz),≤12:1(10Hz to 30kHz) VBW:1Hz to 3MHz,off,1-3 seqrence Signal purity(SSB,1MHz to 4GHz): ≤-100dBc/Hz(10kHz offset,≤-115dBc/Hz(50kHz offset),≤-120dBc/Hz(100kHzoffset)    Spec- trum analyzer Ampl- itude Level Level measuring range:Average:Average noiselevl to +40dBm Average noise level:≤-112dBm(10MHz to 8.5Ghz,RBW 10Hz,VBW 1Hz,input att.setting20dB) Residual reponse:≤-75dBm(1MHz to 8.5GHz,input att.setting 20dB)  Reference level Setting range:-80to +40dBm Accuracy:±0.5dB(-30to +20dBm),±0.75dB(-40to -30dBm,+20to +40dBm),±1.5dB(-60to-40dBm) *After calibration and at freq.100Mhz,span≤2MHz,and in auto mode for inputatt ,RBW,VBW and sweep time settings RBW switching error(after calibration):±0.3dB(RBW:≤300kHz),  Frequency reponse ±0.5dB(100MHz to 2GHz,band:0),±1dB(1.7to8.5GHz,bands:1-/1+)  Linearity( after calibration) LOG:±0.3dB(0to -20dB,RBW:≤100kHz),±1.5dB(0to-80dB,RBW≤10kHz) LIN:±5%(to reference level)   Dynamic  range 2nd harmonics: ≤-70dBc(5to 800MHz,band:0,mixer input level:-30dBm) ≤-80dBc(800to 850MHz,band:0,mixer input level:-30dBm), ≤-90dBc(850MHz to 2.1GHz,bands:1-,mixer input level:-10dBm) Two-signal third-ouder intermodulation distortion:≤-70dBc(10to 50MHz),≤-85dBc(50MHzto 2.1GHz) *Frequency difference between two signals≥50kHz,mixer input level:-30dBm  Sweep Sweep time Setting range:20ms to 1000s(TRACE-FREQ,data points:NORMAL),50ms to 1000s at other conditions Accuracy:±10%(20ms to 200s),±15%(200 to 1000s) Sweep mode:CONTINUOUS,SINGLE Trigger:FREE RUN,TRIGGERED Trigger source:VIDEO,LINE,EXT(±10V),EXT(TTL) Gate mode(OFF,random sweep mode) GATE DELAY:0to 65.5ms(in 1μs steps,GATE END:INT) GATE END:INT/EXT  Time  domain  waveform  display Sweep fime:50,100to 900μs(data point:NORMAL,Onemost significant digit can be set.) 1ms to 1000s(data point:NORMAL,Two most significant digits can be set) 100,200to800μs(data point:DOUBLE,One most significant digit can be set aseven number.) 1ms to 1000s(data point:DOUBLE,Two most significant digits can be set aseven number.) Delay time Pre-trigger.-time span to 0s(in 1point steps) Post trgger:0to 65.5ms(in 1μssteps) Amplitude display resolution:50μsto 49ms,10bits*0.1%of full scale) 50ms to 1000s,14bits(0.01%of full scale)  Detection  mode POS PEAK,SAMPLE,NEG PEAK  Number of  points NOUMAL:501 points,DOUBLE:1002points  AM/FM  demodu- lation Demodulated waveform display and monitoringdemodulated audio signal with internal speaker      Auxiliary inputs/ outputs IF output21.4MHz:-10dBm±2dB(at top of screen,with output terminated by 50Ωteminator),BNC connector  Youtput:0to 0.5V±0.1V(at range between top and bottom of screen,LOG:10dB/div,LIN:10%/div,100MHz and with output terminated by 75Ω terminator),BNC connector External trgger input Input1:max.±10V(in 0.1V steps, rising/falling edges selectable  and pulse width≥10μs),BNC connector Input2:TTL level(rising/falling  edges selectable and pulse width≥10μs, )BNC connector   Power meter Frequency range 100kHz to 5.5GHz  Level range -20to +20dBm  Instrumentation  accuracy ±0.5%  Zero set ±0.5% of full scale at most  sensitive range(100μW range)  Zero shift between  ranges ±0.2% of full scale zero setting at mostsensitive range  Calibration oscillator Freq:50MHz,Output:1.00mW,Accuracy:±1.2%  Applicable power  sensor MA4601A  Others  Display 640×400dot,9-inch EL  Inputs/outputs on rear panel Reference input:10MHz±10Hz,2to 5Vp-p, ≥50Ω,BNC connector Reference buffer output:10MHz,2to  3Vp-p(with the output terminated by  200Ω terminator),BNC connector Separate video output:Compatible  with 8-pin DIN connector  External memory One slot for can be connected  Save/recall Internal memory(4sets of spectrum  and Tx test conditions),can save/recall setting conditions at extemal memory(PMC)  Direct plotting Can hard-copy screen via GPIB2  External control GPIB1 (IEEE488.2) As device controlled by host,all  functions except power swetch Controls other instruments as controller using PTA SH1,AH1,T6,L4,SR1,RL1,PP0,DC1,DT1, C0(C1,C2,C3,and C24with PTA)  GPIB2 (IEEE488.1) Controls other instruments as controller SH1,AH1,T6,L4,SR1,RL1,PP0,DC1,DT1 ,C1,C2,C3,C4,C28   I/O port  Output port A/B:8-bit(TTL level), Input/Output port C/C:4-bit(TTL level), EXclusive port:3-bit(TTL level) Control signal:4(TTL level),+5V  output:Max.50mA  RS-232C (Option 02) Controls other instruments as controller  PTA Language PTL:High level languaeg interpreter based on BASIC  Programming Using external keyboard  Program  memory On PMC or FD Upload/download from/to PC  Programming capacity 900KB  Operating temperature 0°to 50℃  Power 85to 132/170 to 250Vac,47.5 to 63Hz ,≤500VA  Dimensions and mass 426(W)×221.5(H)×451(D)mm,≤27kg  EMC*1 EN55011:1991,Group1,ClassA EN50082-1:1992   Safety EN61010-1:1993(Installation CategoryII ,Pollution DegreeII)

订货信息

Applicable system Measurement software Application software(supplied by PMC)  PDC Option11 MX3512A  PHS Option12  NADC Option13  Digital MCA Option14 MX3513A  GSM Option15 MX3518A  DC1800(PCN)  DECt MX3519A  CT2 MX3520A  General-purpose GMSK -  WCPE Option16 -  RCR STD-39  PACS  TETRA  General-purposeπ/4 DQPSK  备注： 我们的优势： 品种齐全，货源充足，存库雄厚，服务快捷，维修能力强。 _^欢迎来电!上门看货!价格好商量!您的满意是我们的追求！^_^ 我公司对销售的仪器仪表均负责保修一年. 本公司长期供应/租赁/维修二手进口仪器#@网络分析仪，综合测试仪，频谱分析仪，&#深圳网络分析仪厂家直销（讯鑫电子）
