Specifications
|
Accuracy
|
|
Rated capacity(R.C)
|
500kgf, 1tf, 2tf, 3tf, 5tf, 9tf, 10tf, 12tf (4.903kN, 9.807kN, 19.61kN, 29.42kN, 49.0kN, 88.26kN, 98.07kN, 117.7kN)
|
|
Rated output(R.O)
|
2mV/V±0.1%
|
|
Nonlinearity
|
0.03% of R.O.
|
|
Hysteresis
|
0.03% of R.O.
|
|
Repeatability
|
0.25% of R.O.
|
|
Creep(20min)
|
0.03% of R.O.
|
|
Zero balance
|
±5% of R.O.
|
|
Temperature effect, on rated output
|
0.02% of LOAD/10℃
|
|
Temperature effect, on zero balance
|
0.05% of R.O./10℃
|
|
Temperature range, compensated
|
-10~50℃
|
|
Temperature range, safe
|
-20~80℃
|
|
Terminal resistance input
|
350 ±30Ω
|
|
Terminal resistance output
|
350 ±3Ω
|
|
Insulation resistance bridge
|
2000MΩ
|
|
Excitation recommended
|
10V
|
|
Safe overload
|
150% R.C.
|
|
Cable length
|
Φ7±0.3mm 4core, 3m
|
|
|
