Specifications
|
Accuracy
|
|
CXH
|
CXM
|
CXG
|
|
Rated capacity(R.C)
|
1tf, 2tf, 3tf, 5tf, 10tf, 20tf
|
100kgf, 200kgf, 500kgf, 1tf, 2tf, 3tf, 5tf, 10tf, 20tf, 30ft, 50ft, 100tf, 200tf, 300tf, 500tf
|
|
Rated output(R.O)
|
2.0mV/V±0.1%
|
2.0mV/V±0.1(50tf~500tf : 1.5mV/V±0.1%)
|
|
Nonlinearity
|
0.02% of R.O.
|
0.05% of R.O.
|
0.1% of R.O.
(200, 300, 500tf : 0.5% of R.O.)
|
|
Hysteresis
|
0.02% of R.O
|
0.05% of R.O
|
0.1% of R.O.
(200, 300, 500tf : 0.5% of R.O.)
|
|
Repeatability
|
0.02% of R.O
|
0.05% of R.O
|
0.1% of R.O.
|
|
Zero balance
|
±1% of R.O.
|
|
Temperature effect, on rated output
|
0.03% of LOAD/10℃
|
0.1% of LOAD/10℃
|
|
Temperature effect, on zero balance
|
0.03% of R.O./10℃
|
0.1% of R.O./10℃
|
|
Temperature range, compensated
|
-10~60℃
|
|
Temperature range, safe
|
-20~80℃
|
|
Terminal resistance input
|
350±5Ω
|
|
Terminal resistance output
|
350±5Ω
|
|
Insulation resistance bridge/case
|
5000MΩ
|
|
Excitation recommended
|
10V
|
|
Safe overload
|
150% R.C.
|
|
Cable length
|
Φ7mm 4core,3m
|
|
|
