供应OMRON欧姆龙编码器E6H-CWZ5B 2000P/R 现货
| 价 格： | 1.00 | |
| 型号/规格： | E6H-CWZ5B 2000P/R | |
| 品牌/商标： | OMRON |
E6H-CWZ5B 2000P/R
加电压：DC35V以下 同步电流：35mA以下 残留电源：0.7V以下 (同步电流35mA时)
输出电阻：1kΩ 同步电流:30mA以下 残留电源:0.7V以下(同步电流30mA时)
输出电流 H位：I0= -10mA L位：IS=10mA 输出电压V0=2.5V VS=0.5V
响应频率
100kHz
E6H-CWZ6C
E6H-CWZ3E
E6H-CWZ3X
0 V
GND
5 to 24 VDC
35 mA
max.
35 VDC
max.
NPN
transistor
Output signal
(Black: phase A,
White: phase B,
Orange: phase Z)
Blue
Shield
Brown
Black, white,
orange
E6H
main
OFF
ON
OFF
Phase B
Phase Z
Phase A
Phase B
Phase Z
CW
CCW
Open-collector output
Direction of rotation: CW
(as viewed from end of shaft)
Direction of rotation: CCW
(as viewed from end of shaft)
1/4T±1/8T (90˚±45˚)
1/4T±1/8T (90˚±45˚)
Color Terminal
Brown Power supply (+Vcc)
Black Output phase A
White Output phase B
Orange Output phase Z
Blue 0 V (common)
0 V
1 kΩ
5 to 12 VDC
GND
Shield
E6H
main
circuit
30 mA
max.
NPN
transistor
Output signal
(Black: phase A,
White: phase B,
Orange: phase Z)
Blue
Brown
Black, white,
orange
T(360˚)
H
L
H
L
H
L
Phase B
Phase Z
Phase A
Phase B
Phase Z
CW
CCW
Voltage output
Direction of rotation: CW
(as viewed from end of shaft)
Direction of rotation: CCW
(as viewed from end of shaft)
1/4T±1/8T (90˚±45˚)
1/4T±1/8T (90˚±45˚)
0 V
5 to 12 VDC
E6H
Brown
Black, white,
orange
Black/red,
white/red,
orange/red
GND
Shield
Orange: phase Z)
(Black/red: phase A,
White/red: phase B,
Phase B
Note: 1. Receiver: AM26LS32 equivalent
2. "Black/red" indicates a red strip.
C
