供应OMRON欧姆龙编码器E6C2-CWZ5GH 1024P/R现货
| 价 格： | 1.00 | |
| 型号/规格： | E6C2-CWZ5GH 1024P/R | |
| 品牌/商标： | OMRON |
E6C2-CWZ5GH 1024P/R
s (Order Separately) [Refer to Dimensions on Rotary Encoder Accessories.]
：-10～+70°C、保存时：-25～+85°C (无结冰)
环境湿度范围
工作时、保存时：各35～85%RH (无结露)
绝缘电阻
20MΩ以上(DC500V兆)导线端整体与外壳间
耐电压
AC500V 50/60Hz 1min 导线端整体与外壳间
振动(耐久)
10～500Hz 上下振幅 2mm或150m/s2 X、
Refer to Accessories for details.
Power supply
voltage
Output configuration Resolution (pulses/rotation) Model
5 to 24 VDC
Open-collector output
(NPN)
10, 20, 30, 40, 50, 60, 100, 200, 300, 360, 400, 500, 600
E6C2-CWZ6C (resolution) 2M
Example: E6C2-CWZ6C 10P/R 2M
720, 800, 1,000, 1,024, 1,200, 1,500, 1,800, 2,000
12 to 24 VDC
Open-collector output
(PNP)
100, 200, 360, 500, 600
E6C2-CWZ5B (resolution) 2M
Example: E6C2-CWZ5B 100P/R 2M
1,000, 2,000
5 to 12 VDC Voltage output
10, 20, 30, 40, 50, 60, 100, 200, 300, 360, 400, 500, 600
E6C2-CWZ3E (resolution) 2M
Example: E6C2-CWZ3E 10P/R 2M
720, 800, 1,000, 1,024, 1,200, 1,500, 1,800, 2,000
5 VDC Line-driver output
10, 20, 30, 40, 50, 60, 100, 200, 300, 360, 400, 500, 600
E6C2-CWZ1X (resolution) 2M
Example: E6C2-CWZ1X 10P/R 2M
720, 800, 1,000, 1,024, 1,200, 1,500, 1,800, 2,000
Name Model Remarks
Couplings
E69-C06B ---
E69-C68B Different end diameter
E69-C610B Different end diameter
E69-C06M Metal construction
Flanges
E69-FCA ---
E69-FCA02 E69-2 Servo Mounting Bracket provided.
Servo Mounting Bracket E69-2 Provided with E69-FCA02 Flange.
上有环形通、暗的刻线，有光电发射和接收器件读取,获得四组正弦波信号组合成A、B、C、D,每个正弦波相差90度相位差（相对于一个周波为360度），将C、D信号反向，叠加在A、B两相上，可增强稳定信号；另每转输出一个Z相脉冲以代
