供应功率分配器 BP4P1+
| 价 格： | 面议 | |
| 型号/规格： | BP4P1+ | |
| 品牌/商标： | Mini-Circuits |
BP4P1+：Surface Mount Power Splitter/Combiner 功率分配器/合成 SOP-8封装 4 Way-0° 50Ω 1500 to 2500 MHz
Maximum Ratings：
Operating Temperature -40°C to 85°C
Storage Temperature -65°C to 150°C
Power Input (as a splitter) 1.5W max.
Internal Dissipation 0.375W max.
Permanent damage may occur if any of these limits are exceeded
Pin Connections
SUM PORT 2
PORT 1 1
PORT 2 8
PORT 3 5
PORT 4 4
GROUND 3,6,7
Features
• low insertion loss, 0.8 dB typ.
• excellent output VSWR, 1.25:1 typ.
• aqueous washable
• excellent power handling, 1.5W
Applications
• PCS/DCS
• GSM
• WCDMA
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 李小姐
- 电话：0755-83996702/82861853/83017431
- 传真：0755-83017431
- 手机：13760397503
- QQ ：
供应功率分配器 BP4P+
信息内容：BP4P+：Surface Mount Power Splitter/Combiner 功率分配器/合成 SOP-8封装 4 Way-0° 50Ω 1710 to 1990 MHz Maximum Ratings： Operating Temperature -40°C to 85°C Storage Temperature -65°C to 150°C Power Input (as a splitter) 1.5W max. Internal Dissipation 0.375W max. Permanent damage may occur if any of these limits are exceeded Pin Connections SUM PORT 2 PORT 1 1 PORT 2 8 PORT 3 5 PORT 4 4 GROUND 3,6,7 Features • low insertion loss, 0.8 dB typ. • aqueous washable Applications • PCS/DCS • communications systems • instrumentation
供应射频变压器 ADT8-1T+
信息内容：ADT8-1T+：Mini-Circuits 射频变压器 Surface Mount RF Transformer 50Ω 0.1 to 130 MHz Maximum Ratings Operating Temperature -20°C to 85°C Storage Temperature -55°C to 100°C RF Power 0.5W DC Current 30mA Pin Connections PRIMARY DOT 3 PRIMARY 1 SECONDARY DOT 4 SECONDARY 6 SECONDARY CT 5 NOT USED 2 Features • excellent amplitude unbalance, 0.05 dB typ. in 1 dB bandwidth • excellent return loss, 20 dB typ. in 1 dB bandwidth • aqueous washable • protected under US patent 6,133,525 Applications • impedance matching • balanced amplifiers
