供应高通滤波器 HFCN-3100+
| 价 格： | 面议 | |
| 型号/规格： | HFCN-3100+ | |
| 品牌/商标： | Mini-Circuits |
HFCN-3100+：Mini-Circuits 高通滤波器 Ceramic High Pass Filter 50Ω 3400 to 9900 MHz
Maximum Ratings
Operating Temperature -55oC to 100oC
Storage Temperature -55oC to 100oC
RF Power Input* 7W max. at 25ºC
*Passband rating, derate linearly to 3W at 100°C ambient.Permanent damage may occur if any of these limits are exceeded.
Pin Connections
RF IN 1
RF OUT 3
GROUND 2,4,5,6
Features
• Low cost
• Small size
• 5 sections
• Temperature stable
• Excellent power handling, 7W
• Hermetically sealed
• LTCC construction
• Protected by US Patent 7,760,485
Applications
• Sub-harmonic rejection and DC blocking
• Transmitters / receivers
