供应高通滤波器 HFCN-740+
| 价 格： | 面议 | |
| 型号/规格： | HFCN-740+ | |
| 品牌/商标： | Mini-Circuits |
HFCN-740+：Mini-Circuits 高通滤波器 Ceramic High Pass Filter 50Ω 780 to 2800 MHz
Maximum Ratings
Operating Temperature -55°C to 100°C
Storage Temperature -55°C to 100°C
RF Power Input* 7W max. at 25°C
* Passband rating, derate linearly to 3W at 100°C ambient.Permanent damage may occur if any of these limits are exceeded.
Pin Connections
RF IN 1
RF OUT 3
GROUND 2,4
Features
• low cost
• small size
• 7 sections
• temperature stable
• hermetically sealed
• LTCC construction
• excellent power handling, 7W
Applications
• sub-harmonic rejection and dc blocking
• transmitters/receivers
• lab use
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 李小姐
- 电话：0755-83996702/82861853/83017431
- 传真：0755-83017431
- 手机：13760397503
- QQ ：
供应高通滤波器 HFCN-3800+
信息内容：HFCN-3800+：Mini-Circuits 高通滤波器 Ceramic High Pass Filter 50Ω 4250 to 10000 MHz Maximum Ratings Operating Temperature -55ºC to 100ºC Storage Temperature -55ºC to 100ºC RF Power Input* 7W max. at 25ºC *Passband rating, derate linearly to 3W at 100°C ambient.Permanent damage may occur if any of these limits are exceeded. Pin Connections RF IN 1 RF OUT 3 GROUND 2,4,5,6 Features • Low cost • Small size • 5 sections • Temperature stable • Excellent power handling, 7W • Hermetically sealed • LTCC construction • Protected by US Patent 7,760,485 Applications • Sub-harmonic rejection and DC blocking • Transmitters / receivers Mini-Circuits：主要产品
供应高通滤波器 HFCN-3100+
信息内容：HFCN-3100+：Mini-Circuits 高通滤波器 Ceramic High Pass Filter 50Ω 3400 to 9900 MHz Maximum Ratings Operating Temperature -55oC to 100oC Storage Temperature -55oC to 100oC RF Power Input* 7W max. at 25ºC *Passband rating, derate linearly to 3W at 100°C ambient.Permanent damage may occur if any of these limits are exceeded. Pin Connections RF IN 1 RF OUT 3 GROUND 2,4,5,6 Features • Low cost • Small size • 5 sections • Temperature stable • Excellent power handling, 7W • Hermetically sealed • LTCC construction • Protected by US Patent 7,760,485 Applications • Sub-harmonic rejection and DC blocking • Transmitters / receivers
