供应混频器 ADE-5+
| 价 格： | 面议 | |
| 型号/规格： | ADE-5+ | |
| 品牌/商标： | Mini-Circuits |
ADE-5+：Mini-Circuits 混频器 Surface Mount Frequency Mixer Level 7 (LO Power +7 dBm) 5 to 1500 MHz
Maximum Ratings
Operating Temperature -40°C to 85°C
Storage Temperature -55°C to 100°C
RF Power 50mW
IF Current 40mA
Permanent damage may occur if any of these limits are exceeded
Pin Connections
LO 6
RF 3
IF 2
GROUND 1,4,5
Features
• low conversion loss, 6.6 dB typ.
• excellent L-R isolation, 40 dB typ.
• excellent IP3, 15 dBm
• aqueous washable
• protected by U.S. Patent 6,133,525
Applications
• cellular
• PCS
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 李小姐
- 电话：0755-83996702/82861853/83017431
- 传真：0755-83017431
- 手机：13760397503
- QQ ：
供应混频器 ADE-30+
信息内容：ADE-30+：Mini-Circuits混频器 Surface Mount Frequency Mixer Level 7 (LO Power +7 dBm) 200 to 3000 MHz Maximum Ratings Operating Temperature -40°C to 85°C Storage Temperature -55°C to 100°C RF Power 50mW IF Current 40mA Permanent damage may occur if any of these limits are exceeded. Pin Connections LO 6 RF 3 IF 2 GROUND 1,4,5 Features • low conversion loss, 4.5 dB typ. • excellent L-R isolation, 35 dB typ. • low profile package • aqueous washable • protected by U.S. Patent 6,133,525 Applications • cellular • PCN • instrumentation • ISM
供应固定衰减器 PAT-30+
信息内容：PAT-30+：微型陶瓷固定衰减器 50欧 1W 30dB DC to 7000 MHz Maximum Ratings（额定值）： Operating Temperature 工作温度 -55°C to 100°C Storage Temperature 存储温度 -55°C to 100°C Pin Connections： ● INPUT 1 ● OUTPUT 3 ● GROUND 2,4 Features： ● wideband, DC to 7000 MHz ● excellent VSWR, through entire band ● miniature size ● aqueous washable Applications： ● power leveling ● impedance match improvement
