供应功率分配器 SCN-2-35+
| 价 格： | 面议 | |
| 型号/规格： | SCN-2-35+ | |
| 品牌/商标： | Mini-Circuits |
SCN-2-35+：Mini-Circuits 功率分配器 Ultra-Small Ceramic Power Splitter/Combiner 2 Way-0° 50Ω 2825 to 3700 MHz
Maximum Ratings
Operating Temperature -55°C to 100°C
Storage Temperature -55°C to 100°C
Power Input (as a splitter) 4W* max.
*Derate linearly to 1.3W at 100°C ambient, power input as combiner
is limited by rating of external 100Ω Resistor.
Permanent damage may occur if any of these limits are exceeded
Pin Connections
SUM PORT 2
PORT 1 6
PORT 2 4
GROUND 1,3,5
PORT 1-2 resistor external 100 OHMS
Features
• isolation resistor, external 100 ohms
• low insertion loss, 0.4 dB typ.
• excellent amplitude unbalance, 0.1 dB typ.
• excellent phase unbalance, 0.8 deg. typ.
• high isolation, 28 dB typ.
• excellent power handling, 4W as splitter
• small size, 0.12”X0.06”X0.035”
• ESD non-sensitive
• temperature stable LTCC technology
• wrap around terminations for excellent solderability
• low cost
• protected by US patent 6,967,544
Applications
• amateur radio
• defense
• wireless communication
浩时健这些产品广泛用于高科技的航空、航天、邮电、军工、通信、工业控制以及消费电子产品领域;并利用所代理的产品为客户研制和开发各种通信产品,包括语音信箱、用户接口板、无线数字扩频设备、微波、光纤直放站等设备。浩时健Mini-Circuits：主要产品混频器、功分器/合路器、阻抗变换器、衰减器、匹配负载、变压器、电缆、转接头、隔直模块、 功率检波器、放大器、调制器/解调器、定向耦合器、相位检波器、线延伸器、限幅器、倍频器、压控振荡器、偏置器、扼流圈、移相器、滤波器、开关。
备注：本司长期现货供应型号：
SBL-1+ SBL-1-1+ SBL-1MH+ SBL-1X+ SBL-1XLH+ SBL-1ZMH SBL-2LH+ SBL-3+ SBL-11+ SBLP-39 SBLP-117+ SBLP-156 SBLP-200+ SBLP-300 SBLP-467 SBLP-933 SBLP-1870 SBP-10.7+ SBP-21.4 SBP-30+ SBP-60+ SBP-70 SBTC-2-10+ SBTC-2-10-75+ SCN-2-11+,SCN-2-15+,SCN-2-19+,SCN-2-22+,SCN-2-27+,SCN-2-35+,SCN-2-45+,SCN-2-65+,SCN-3-13+,SCN-3-16+,SCN-3-28+,PLP-1.9+,PLP-10.7+,PLP-10.7-75+,PLP-100+,PLP-100-75+,PLP-1000+,PLP-1200+,PLP-15+,PLP-15-75+,PLP-150+,PLP-2.5+,PLP-200+,PLP-21.4+,PLP-21.4-75+,PLP-250+,PLP-30+,PLP-30-75+,PLP-300+,PLP-450+,PLP-5+,PLP-50+,PLP-550+,PLP-600+,PLP-600-750+,PLP-7-75+,PLP-750+,PLP-800+,PLP-850+,PLP-90+,LFCN-1000+,LFCN-1000D+,LFCN-105+,LFCN-120+,LFCN-1200+,LFCN-1200D+,LFCN-1325+,LFCN-1400+,LFCN-1400D+,LFCN-1450+,LFCN-1500+,LFCN-1500D+,LFCN-1525+,LFCN-1575+,LFCN-160+,LFCN-1700+,LFCN-1700D+...
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 李小姐
- 电话：0755-83996702/82861853/83017431
- 传真：0755-83017431
- 手机：13760397503
- QQ ：
供应功率分配器 SCN-3-16+
信息内容：SCN-3-16+：Mini-Circuits 功率分配器 Ultra-Small Ceramic Power Splitter/Combiner 3 Way-0° 50Ω 950 to 1600 MHz Maximum Ratings Operating Temperature -55°C to 100°C Storage Temperature -55°C to 100°C Power Input (as a splitter) 15W* max. * Derate linearly to 6W at 100°C ambient. Permanent damage may occur if any of these limits are exceeded Pin Connections SUM PORT 2 PORT 1 6 PORT 2 5 PORT 3 4 GROUND 1,3 PORT 1-2, 2-3 resistor external 124 ohms PORT 1-3 resistor external 127 ohms Features • isolation resistors, external • low insertion loss, 0.6 dB typ. • excellent amplitude unbalance, 0.2 dB typ. • very good phase unbalance, 3 deg. typ. • high isolation, 15 dB typ. • excellent power handling, 15W as splitter • small size, 0.12"X0.06"X0.035" • ESD non-sensitive • temperature stable LTCC technology • wrap a...
供应功率分配器 SCN-2-15+
信息内容：SCN-2-15+：Mini-Circuits 功率分配器 Ultra-Small Ceramic Power Splitter/Combiner 2 Way-0° 50Ω 1100 to 1450 MHz Maximum Ratings Operating Temperature -55°C to 100°C Storage Temperature -55°C to 100°C Power Input (as a splitter) 20W* max. *Derate linearly to 6W at 100°C ambient. Permanent damage may occur if any of these limits are exceeded Pin Connections SUM PORT 2 PORT 1 6 PORT 2 4 GROUND 1,3,5 PORT 1-2 resistor external 100 OHMS Features • isolation resistor, external 100 ohms • low insertion loss, 0.4 dB typ. • excellent amplitude unbalance, 0.2 dB typ. • excellent phase unbalance, 1.5 deg. typ. • high isolation, 25 dB typ. • excellent power handling, 20W as splitter • small size, 0.12”X0.06”X0.035” • ESD non-sensitive • temperature stable LTCC technology • wrap around terminations for excellent sold...
