供应EPCOS压敏电阻B72280B461K001V57 B80K460
| 价 格： | 面议 | |
| 型号/规格： | B72280B461K001V57 B80K460 | |
| 品牌/商标： | EPCOS | |
| 环保类别： | 无铅环保型 |
B72280B461K001V57 B80K460
Leaded varistors
StandarD series
Construction
Round varistor element, leaded
Coating: epoxy resin, flame-retardant to UL 94 V-0
Features
Wide operating voltage range 11 … 1100 V
High surge current ratings up to 8 kA
No derating up to 85 °C ambient temperature
PSpice models
Approvals
UL
RMS
CSA (all types ≥ K115)
VDE
CQC S05/07 (K11 … K460), S10/S14 (K11 … K680), S20 (K11 … K1000)
IEC
Delivery mode
Bulk (standard), taped versions on reel or in Ammo pack upon request.
For further details refer chapter "Taping, packaging and lead configuration" for leaded
varistors.
Options
S10* types with lead spacing 5.0 mm and S20* types with lead spacing 7.5 mm are also
available on request.
General technical data
Climatic category to IEC 60068-1 40/85/56
Operating temperature to IEC 61051 40 ... + 85 °C
Storage temperature 40 ... +125 °C
Electric strength to IEC 61051 ≥ 2.5 kV
Insulation resistance to IEC 61051 ≥ 100 MΩ
Response time < 25 ns
RMS
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 杨先生
- 电话：0755-32826987
- 传真：0755-23221987
- 手机：18926016675
- QQ ：
供应EPCOS压敏电阻B72210S 301K101V87 S10K300
信息内容：B72210S 301K101V87 S10K300 Leaded varistors StandarD series Construction Round varistor element, leaded Coating: epoxy resin, flame-retardant to UL 94 V-0 Features Wide operating voltage range 11 … 1100 V High surge current ratings up to 8 kA No derating up to 85 °C ambient temperature PSpice models Approvals UL RMS CSA (all types ≥ K115) VDE CQC S05/07 (K11 … K460), S10/S14 (K11 … K680), S20 (K11 … K1000) IEC Delivery mode Bulk (standard), taped versions on reel or in Ammo pack upon request. For further details refer chapter "Taping, packaging and lead configuration" for leaded varistors. Options S10* types with lead spacing 5.0 mm and S20* types with lead spacing 7.5 mm are also available on request. General technical data Climatic category to IEC 60068-1 40/85/56 Operating temperature to IEC 61051 40 ... + 85 °C Storage temperature 40 ... +125 °C Electric strength to IEC 61051 ≥ 2.5 kV Insulation resistance to IEC 61051 ≥ 100 M...
供应EPCOS压敏电阻B72220S2381K101V87 S20K385E2
信息内容：B72220S2381K101V87 S20K385E2 Leaded varistors B722* AdvanceD series Construction Round varistor element, leaded Coating: epoxy resin, flame-retardant to UL 94 V-0 Features High-energy AdvanceD series E2 High surge current ratings up to 10 kA High energy ratings up to 440 J Wide operating voltage range 130 … 680 V PSpice models Approvals RMS UL CSA VDE CQC S05/07 (K11 … K460), S10/S14 (K11 … K680), S20 (K11 … K1000) IEC Delivery mode Bulk (standard), taped versions on reel or in Ammo pack upon request. For further details refer chapter "Taping, packaging and lead configuration" for leaded varistors. General technical data Climatic category to IEC 60068-1 40/85/56 Operating temperature to IEC 61051 40 ... + 85 °C Storage temperature 40 ... +125 °C Electric strength to IEC 61051 ≥ 2.5 kV Insulation resistance to IEC 61051 ≥ 100 MΩ Response time < 25 ns RMS
