供应EPCOS压敏电阻B72207S1140K201V57 S07K14AUTOS2D1
| 价 格： | 面议 | |
| 型号/规格： | B72207S1140K201V57 S07K14AUTOS2D1 | |
| 品牌/商标： | EPCOS | |
| 环保类别： | 无铅环保型 |
B72207S1140K201V57 S07K14AUTOS2D1
Leaded varistors B722*
Automotive series
Construction
Round varistor element, leaded
Coating: epoxy resin (D1: phenolic resin),
flame-retardant to UL 94 V-0
Features
High energy absorption,
particularly for load dump
Jump-start strength
Stable protection level, minimum leakage current
High resistance to cyclic temperature stress
PSpice models
High operating temperature range up to 125 °C
Delivery mode
Bulk (standard), taped versions on reel or in Ammo pack upon request.
For further details refer chapter "Taping, packaging and lead configuration" for leaded
varistors.
General technical data
Climatic category to IEC 60068-1 40/85/56
for D1 types 40/125/56
Operating temperature to IEC 61051 40 ... + 85 °C
for D1 types 40 ... +125 °C
Storage temperature 40 ... +125 °C
for D1 types 40 ... +150 °C
Electric strength to IEC 61051 ≥ 2.5 (not D1 types) kV
Insulation resistance to IEC 61051 ≥ 100 (not D1 types) MΩ
Response time < 25 ns
RMS
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 杨先生
- 电话：0755-32826987
- 传真：0755-23221987
- 手机：18926016675
- QQ ：
供应EPCOS压敏电阻B72280B461K001V57 B80K460
信息内容：B72280B461K001V57 B80K460 Leaded varistors StandarD series Construction Round varistor element, leaded Coating: epoxy resin, flame-retardant to UL 94 V-0 Features Wide operating voltage range 11 … 1100 V High surge current ratings up to 8 kA No derating up to 85 °C ambient temperature PSpice models Approvals UL RMS CSA (all types ≥ K115) VDE CQC S05/07 (K11 … K460), S10/S14 (K11 … K680), S20 (K11 … K1000) IEC Delivery mode Bulk (standard), taped versions on reel or in Ammo pack upon request. For further details refer chapter "Taping, packaging and lead configuration" for leaded varistors. Options S10* types with lead spacing 5.0 mm and S20* types with lead spacing 7.5 mm are also available on request. General technical data Climatic category to IEC 60068-1 40/85/56 Operating temperature to IEC 61051 40 ... + 85 °C Storage temperature 40 ... +125 °C Electric strength to IEC 61051 ≥ 2.5 kV Insulation resistance to IEC 61051 ≥ 100 MT...
供应EPCOS压敏电阻B72210S 301K101V87 S10K300
信息内容：B72210S 301K101V87 S10K300 Leaded varistors StandarD series Construction Round varistor element, leaded Coating: epoxy resin, flame-retardant to UL 94 V-0 Features Wide operating voltage range 11 … 1100 V High surge current ratings up to 8 kA No derating up to 85 °C ambient temperature PSpice models Approvals UL RMS CSA (all types ≥ K115) VDE CQC S05/07 (K11 … K460), S10/S14 (K11 … K680), S20 (K11 … K1000) IEC Delivery mode Bulk (standard), taped versions on reel or in Ammo pack upon request. For further details refer chapter "Taping, packaging and lead configuration" for leaded varistors. Options S10* types with lead spacing 5.0 mm and S20* types with lead spacing 7.5 mm are also available on request. General technical data Climatic category to IEC 60068-1 40/85/56 Operating temperature to IEC 61051 40 ... + 85 °C Storage temperature 40 ... +125 °C Electric strength to IEC 61051 ≥ 2.5 kV Insulation resistance to IEC 61051 ≥ 100 M...
