薄膜电容
| 价 格： | 面议 | |
| 型号/规格： | 800V200UF | |
| 品牌/商标： | VTCO | |
| 环保类别： | 无铅环保型 | |
| 安装方式： | 直插式 | |
| 包装方式： | 散装 |
Article table/参数表
400Vdc ,250Vac ,50/60Hz
Part Number
CAP
μF
Dimension (mm)
Irms max
A
ESR
(mΩ)
RTH
(k/W)
D
H
P
SCF-400-30
30
55
55
22.0
27
2.8
9.7
SCF-400-50
50
55
70
22.0
29
3.0
8.1
SCF-400-60
60
60
70
28.5
31
2.7
7.5
SCF-400-70
70
65
70
28.5
34
2.5
7.0
SCF-400-100
100
60
125
22.0
44
2.2
5.0
SCF-400-120
120
60
125
28.5
47
2.0
4.5
SCF-400-130
130
65
125
28.5
49
2.0
4.3
SCF-400-150
150
76
125
32.0
53
1.9
3.7
SCF-400-200
200
86
125
32.0
59
2.8
3.3
SCF-400-250
250
76
180
32.0
68
1.7
2.6
SCF-400-350
350
86
180
32.0
74
1.6
2.3
600Vdc .330Vac 50/60Hz
|
Part Number |
CAP μF |
Dimension (mm) |
Irms max A |
ESR (mΩ) |
RTH (k/W) |
||
|
D |
H |
P |
|||||
|
SCF-600-15 |
15 |
55 |
55 |
22.0 |
24 |
3.5 |
9.7 |
|
SCF-600-25 |
25 |
55 |
70 |
22.0 |
25 |
4.0 |
8.1 |
|
SCF-600-33 |
33 |
60 |
70 |
28.5 |
30 |
3.5 |
7.5 |
|
SCF-600-40 |
40 |
65 |
70 |
28.5 |
32 |
3.0 |
7.0 |
|
SCF-600-50 |
50 |
55 |
125 |
22.0 |
40 |
2.9 |
5.0 |
|
SCF-600-65 |
65 |
60 |
125 |
28.5 |
44 |
2.5 |
4.5 |
|
SCF-600-75 |
75 |
65 |
125 |
28.5 |
47 |
2.2 |
4.3 |
|
SCF-600-100 |
100 |
76 |
125 |
32.0 |
52 |
2.0 |
3.7 |
|
SCF-600-130 |
130 |
86 |
125 |
32.0 |
58 |
1.8 |
3.3 |
|
SCF-600-150 |
150 |
76 |
180 |
32.0 |
65 |
1.7 |
2.6 |
|
SCF-600-200 |
200 |
86 |
180 |
32.0 |
73 |
1.6 |
2.3 |
700Vdc ,400Vac 50/60Hz
|
Part Number |
CAP μF |
Dimension (mm) |
Irms max A |
ESR (mΩ) |
RTH (k/W) |
||
|
D |
H |
P |
|||||
|
SCF-700-12 |
12 |
55 |
55 |
22.0 |
24 |
3.5 |
9.7 |
|
SCF-700-15 |
15 |
55 |
70 |
22.0 |
23 |
5.0 |
8.1 |
|
SCF-700-20 |
20 |
60 |
70 |
28.5 |
25 |
4.0 |
7.5 |
|
SCF-700-25 |
25 |
65 |
70 |
28.5 |
30 |
3.5 |
7.0 |
|
SCF-700-33 |
33 |
55 |
125 |
22.0 |
38 |
3.0 |
5.0 |
|
SCF-700-40 |
40 |
60 |
125 |
28.5 |
40 |
2.5 |
4.5 |
|
SCF-700-50 |
50 |
65 |
125 |
28.5 |
45 |
2.3 |
4.3 |
|
SCF-700-70 |
70 |
76 |
125 |
32.0 |
50 |
2.0 |
3.7 |
|
SCF-700-100 |
100 |
76 |
180 |
32.0 |
65 |
1.8 |
2.6 |
|
SCF-700-130 |
130 |
86 |
180 |
32.0 |
70 |
1.7 |
2.3 |
850Vdc ,450Vac 50/60Hz
|
Part Number |
CAP μF |
Dimension (mm) |
Irms max A |
ESR (mΩ) |
RTH (k/W) |
||
|
D |
H |
P |
|||||
|
SCF-850-8 |
8 |
55 |
55 |
22.0 |
23 |
4.0 |
9.7 |
|
SCF-850-12 |
12 |
55 |
70 |
22.0 |
23 |
5.0 |
8.1 |
|
SCF-850-15 |
15 |
60 |
70 |
28.5 |
25 |
4.0 |
7.5 |
|
SCF-850-22 |
22 |
55 |
125 |
22.0 |
35 |
3.5 |
5.0 |
|
SCF-850-33 |
33 |
65 |
125 |
28.5 |
40 |
2.5 |
4.3 |
|
SCF-850-47 |
47 |
76 |
125 |
32.0 |
50 |
2.2 |
3.7 |
|
SCF-850-60 |
60 |
86 |
125 |
32.0 |
55 |
2.0 |
3.3 |
|
SCF-850-70 |
70 |
76 |
180 |
32.0 |
62 |
2.0 |
2.6 |
|
SCF-850-90 |
90 |
86 |
180 |
32.0 |
70 |
1.8 |
2.3 |
