谐振薄膜电容
| 价 格： | 面议 | |
| 型号/规格： | 800V80UF | |
| 品牌/商标： | VTCO | |
| 环保类别： | 无铅环保型 | |
| 安装方式： | 直插式 | |
| 包装方式： | 散装 |
Un=400Vdc
|
Part Number |
CAP μF |
Dimension (mm) |
du/dt v/μs |
Irms max A |
ESR mΩ |
Output |
|
|
L |
D |
insert |
|||||
|
SCLS-400-20-1 |
20 |
40 |
44 |
70 |
27 |
3.5 |
M5 |
|
SCLS-400-25-1 |
25 |
50 |
47 |
60 |
32 |
3.0 |
M6 |
|
SCLS-400-30-1 |
30 |
50 |
50 |
60 |
37 |
2.8 |
M6 |
|
SCLS-400-40-1 |
40 |
50 |
58 |
60 |
46 |
2.5 |
M6 |
|
SCLS-400-50-1 |
50 |
50 |
64 |
60 |
54 |
2.2 |
M8 |
|
SCLS-400-60-1 |
60 |
60 |
57 |
60 |
46 |
2.9 |
M6 |
|
SCLS-400-80-1 |
80 |
60 |
66 |
60 |
56 |
2.0 |
M8 |
|
SCLS-400-100-1 |
100 |
60 |
74 |
60 |
66 |
1.8 |
M8 |
Un=800Vdc
|
Part Number |
CAP μF |
Dimension (mm) |
du/dt v/μs |
Irms max A |
ESR mΩ |
Output |
|
|
L |
D |
insert |
|||||
|
SCLS-800-10-1 |
10 |
40 |
42 |
80 |
25 |
4.5 |
M5 |
|
SCLS-800-15-1 |
15 |
50 |
44 |
70 |
32 |
3.3 |
M6 |
|
SCLS-800-20-1 |
20 |
50 |
52 |
70 |
40 |
2.8 |
M6 |
|
SCLS-800-25-1 |
25 |
50 |
58 |
70 |
45 |
2.5 |
M6 |
|
SCLS-800-30-1 |
30 |
50 |
63 |
70 |
50 |
2.1 |
M6 |
|
SCLS-800-40-1 |
40 |
60 |
63 |
50 |
48 |
3.0 |
M8 |
|
SCLS-800-50-1 |
50 |
60 |
70 |
50 |
55 |
2.6 |
M8 |
|
SCLS-800-60-1 |
60 |
60 |
76 |
50 |
65 |
2.3 |
M8 |
|
SCLS-800-80-1 |
80 |
60 |
88 |
50 |
80 |
2.0 |
M8 |
|
SCLS-800-100-1 |
100 |
60 |
98 |
50 |
95 |
1.8 |
M8 |
Un=1200Vdc
|
Part Number |
CAP μF |
Dimension (mm) |
du/dt v/μs |
Irms max A |
ESR mΩ |
Output |
|
|
L |
D |
insert |
|||||
|
SCLS-1200-5-1 |
5 |
40 |
44 |
120 |
23 |
5.0 |
M6 |
|
SCLS-1200-10-1 |
10 |
50 |
58 |
100 |
38 |
3.3 |
M6 |
|
SCLS-1200-15-1 |
15 |
50 |
70 |
100 |
52 |
2.6 |
M8 |
|
SCLS-1200-20-1 |
20 |
60 |
66 |
80 |
45 |
3.3 |
M8 |
|
SCLS-1200-25-1 |
25 |
60 |
74 |
80 |
55 |
3.0 |
M8 |
|
SCLS-1200-30-1 |
30 |
60 |
45 |
80 |
65 |
2.6 |
M8 |
|
SCLS-1200-40-1 |
40 |
60 |
45 |
80 |
78 |
2.3 |
M8 |
|
SCLS-1200-50-1 |
50 |
60 |
45 |
80 |
90 |
2.0 |
M8 |
