SPI功率驱动器SPI(TTL) Controller

LT-280 SPI功率驱动器(8像素) SPI Driver (8 Pixels/24CH)

SPI功率驱动器可以接收市面上输出标准SPI（TTL）数码信号LED控制器控制，可广泛应用于所有不带驱动芯片的LED灯具的控制，加上驱动器使变化效果不再单一，可实现更丰富的变化效果。可实现LED灯具的全彩扫描、追逐、动画等等变化，控制路数和功率可无限扩展。SPI(TTL) Controllercan receive SPI (TTL) digital signals, widely used for controlling LED lights without driving chips, it makes the changing effects more vivid, and can realize RGB scanning, color chasing, animation, etc., the control channels and power can be expanded unlimitedly.

注：除接受SPI（TTL）信号控制外，SPI功率驱动器另外配合上我们公司的LT-8020 DMX512信号解码器，可以接受国际标准的DMX信号独立编程控制。 Note：Besides receiving SPI(TTL) signal, it can work with ourLT-8020 DMX512 Decoder,receive international standard DMX512 signal to program separately.

dzsc/19/0963/19096364.jpg

产品参数Product Parameter

LT-280 SPI功率驱动器(8像素) SPI Driver (8 Pixels/24CH)

接收信号Input signal: SPI (TTL) signal

输入电源Input power: DC5V～DC24V

负载电流Max load current: 3A/路×24路3A/CH×24

输出功率Max output power: 360W/864W/1728W(5V/12V/24V)

工作温度Working temperature: -30℃～65℃

产品尺寸Dimension: L260×W120×H40mm

包装尺寸Package Size: L290×W130×H46mm

重量(毛重)Weight (G.W):860g
