供应晶采光电10.4寸AM640480E TTL接口 TFT
| 价 格： | 1.00 | |
| 是否提供加工定制： | 是 | |
| 品牌/商标： | 晶采光电 | |
| 型号/规格： | AM640480E | |
| 种类： | TFT型液晶屏(模块) | |
| 屏幕尺寸： | 10.4（英寸） | |
| 色彩： | 265K | |
| 亮度： | 300 | |
| 对比度： | 500：1 | |
| 分辨率： | 640480 | |
| 点距： | 0.33 (W) x 0.33 (H)（mm） | |
| 响应时间： | 25（ms） | |
| 可视角度： | 85/85/85/85（°） |
dzsc/19/0750/19075047.jpg
1. Introduction
Ampire Display Module AM640480ETMCW00 is a color active matrix TFT-LCD
that uses amorphous silicon TFT as a switching device . This model is composed of
a TFT-LCD panel , a driving circuit and a backlight system . This TFT-LCD has a
10.4-inch diagonally measured active display area with VGA resolution(640(R.G.B)
X 480) and can display up to 262,144 colors .
1-1. Features
- Wide viewing angle.
- High contrast radio
- High operating temperature
- High color saturation
1-2. Applications
● Panel PC
● HMI (Human machine interface)
● Industrial application
● POS
2. Physical specifications
Item Specifications unit
Display resolution(dot) 640 x RGB (W) x 480(H) dots
Active area 211.2 (W) x 158.4 (H) mm
Screen size 10.4(Diagonal) inch
Pixel pitch 0.33 (W) x 0.33 (H) mm
Color configuration R.G.B Vertical stripe
Overall dimension 225.5±0.5(W)x176.3±0.5(H)x9.5±0.5(D) mm
Weight 440(typ) g
Surface treatment Antiglare , Hard-Coating(3H)
Backlight unit Two CCFL
Input signal TTL
Display color 262,144 colors
