排单奇美TV液晶屏47寸V470H2(120Hz)
| 价 格： | 480.00 | |
| 品牌/商标： | 奇美cmo | |
| 型号/规格： | V470H2(120Hz) | |
| 尺寸： | 47（寸） | |
| 颜色： | 262k | |
| 像素点阵： | 1920x1080 | |
| 接口： | lvds | |
| 亮度： | 500 | |
| 对比度： | 4000：1 | |
| 连接方式： | TAB | |
| 种类： | LCD液晶屏 |
奇美电子为全球前四大液晶电视面板供货商之一，从26英寸以上到57英寸以下液晶电视整个产品线均已量产，包括26英寸TN液晶电视入门机型，32到42英寸以上主流机型，到52、57英寸等大尺寸电视应用面板，以及大尺寸高分辨率47与56英寸液晶电视面板，规格与尺寸已相当完备，可充分满足消费者的视觉需求。
| Panel Size | 47" |
| Technology | LCS MVA |
| Resolution | 1920x1080 |
| Number of Pixels | 2.1Mx (R,G,B) |
| Pixel Pitch(mm) | 0.5415 |
| PPI | 47 |
| Active Area(mm) | 1039.68x584.82 |
| Outline(mm) (w/inverter) | 1096x640x53.7 |
| Luminance(nits) | 500 |
| View Angle (U/D/R/L,CR>20) | 88/88/88/88 |
| Contrast Ratio | 4000:1 |
| Color Depth | 10bit (1.07G) |
| Color Gamut (NTSC) | 72% |
| Response Time(ms) | 4 (Gray to Gray) |
| Weight (g) | 13500 |
| Power Consumption(W) | 130W |
| Electrical Interface | 2ch LVDS |
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 黄熙承
- 电话：0755-83954981
- 传真：0755-83954981
- 手机：
- QQ ：
香港交群创新奇美14.0寸液晶屏N140B6-L01
信息内容：*香港现货2541片，美金计价，有兴趣的厂家请电询 1.1 OVERVIEWN140B6-L01 is a 14.0” TFT Liquid Crystal Display module with LED Backlight unit and 40 pins LVDSinterface. This module supports 1366 x 768 HD mode and can display 262,144 colors. The optimumviewing angle is at 6 o’clock direction.1.2 FEATURES- Aspect ratio 16:9- HD (1366 x 768 pixels) resolution- 3.3V LVDS (Low Voltage Differential Signaling) interface with 1 pixel/clock- Meet RoHS requirement- LED Backlight1.3 APPLICATION- TFT LCD Notebook1.4 GENERAL SPECIFICATI0NSItem Specification Unit NoteActive Area 309.40 (H) x 173.95 (V) (14.0” diagonal) mmBezel Opening Area 313.51 (H) x 177.35 (V) mm (1)Driver Element a-si TFT active matrix - -Pixel Number 1366 x R.G.B. x 768 pixel -Pixel Pitch 0.2265 (H) x 0.2265 (V) mm -Pixel Arrangement RGB vertical stripe - -Display Colors 262,144 color -Transmissive Mode Normally white - -Surface Treatment Hard coating (3H), Anti-glare type - -1.5 MECHANICAL SPECIFICATIONSItem ...
供应奇美筆記本液晶屏13.3寸N133I6-L0A(图)
信息内容：奇美电子以优越前瞻技术和设计能力，提供轻薄化、广视角、省电、高亮度的全系列宽屏幕笔记本电脑液晶显示器，为信息产品带来更多方便性。产品涵括8.9吋至18.4吋宽屏幕笔记本电脑液晶显示器，薄型化产品种类齐全，满足多功能应用方面的可携式娱乐显示。 Model Name N133I6-L0A Panel Size 13.3" Wide Technology TN Resolution 1280x800 Pixel Pitch(mm) 0.2235 Active Area(mm) 286.08x178.8 Outline(mm) 304.75x203.2x3.85 Luminance(nits) 300 View Angle (U/D/R/L) 20/45/45/45 Contrast Ratio 300:1 Support Color 262K Power Consumption (w) 4.8 Response Time(ms) 12 Weight (g) 245 max Electrical Interface LVDS Mass Production MP Remark LED, Ultra Slim, Super Light, 16:10
