香港交瀚彩10.1寸液晶屏HSD101PFW1-A
| 价 格： | 26.00 | |
| 是否提供加工定制： | 否 | |
| 品牌/商标： | 瀚宇彩晶Hannstar | |
| 型号/规格： | HSD101PFW1-A | |
| 种类： | LCD液晶屏 | |
| 屏幕尺寸： | 10.2（英寸） |
*香港大量现货供应10寸，10.1寸笔记本面板，品牌奇美，群创，瀚彩，美金结算，起订量1000pcs，需要的工厂请电询
1.1 Introduction
HannStar Display model HSD101PFW1-A is a color active matrix thin film
transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a
switching device. This model is composed of a TFT LCD panel, a driving circuit
and a back light system. This TFT LCD has a 10.1 (16:9) inch diagonally
measured active display area with WSVGA (1024 horizontal by 576 vertical pixel)
resolution.
1.2 Features
10.1 (16:9 diagonal) inch configuration
One channel LVDS interface
262K color by 6 bit R.G.B signal input
RoHS Compliance
Halogen Free
1.3 Applications
Mobile NB
Digital Photo frame
Display terminal for AV application
1.4 General information
Item Specification Unit
Outline Dimension 235 x 143 x 4.9 (Typ.) mm
Display area 222.72(H) x 125.28(V) mm
Number of Pixel 1024 RGB (H) x 576(V) pixels
Pixel pitch 0.2175(H) x 0.2175(V) mm
Pixel arrangement RGB Vertical stripe
Display mode Normally white
NTSC 50 %
Surface treatment Anti-Glare, Hard-Coating (3H)
Weight 185 (Typ.) g
Back-light White LED
Logic System Power 1.1 (Max.) W
Consumption B/L System (TBD) (Max.) W
Packing form
(1) Package quantity in one carton: 50 pieces.
(2) Carton size: 460mm×361mm×321mm.
