UTC品牌30V低导通阻值低压MOS管 UT4410
| 价 格： | 0.58 | |
| 品牌/商标： | UTC(台湾友顺） | |
| 型号/规格： | UT4410 | |
| 种类： | 绝缘栅(MOSFET) | |
| 沟道类型： | N沟道 | |
| 导电方式： | 增强型 | |
| 用途： | SW-REG/开关电源 | |
| 封装外形： | SMD(SO)/表面封装 | |
| 材料： | N-FET硅N沟道 | |
| 耗散功率： | 3600 | |
| 漏极电流： | 11600 |
N-CHANNEL 30-V (D-S) MOSFET
DESCRIPTION
As advanced N-channel logic level enhancement MOSFET,
the UT4410 is produced using UTC’s high cell density, DMOS
trench technology. which has been specially tailored to minimize
the on-resistance and maintain low gate charge for superior
switching performance.
These devices can be particularly suited for such low voltage
applications: cellular phone and notebook computer power
management and other battery powered circuits where high-side
switching and low in-line power loss are needed in a very small
outline surface mount package.
FEATURES
* RDS(ON) < 18mΩ @VGS = 4.5V
* RDS(ON) < 12mΩ @VGS = 10 V
* Ultra low gate charge ( typical 11 nC )
* Low reverse transfer capacitance ( CRSS = typical 35 pF )
* Fast switching capability
* Avalanche energy specified
* Improved dv/dt capability, high ruggedness
