ST品牌30V低导通阻值低压N-MOS管 STS10N3LH5
| 价 格： | 0.51 | |
| 品牌/商标： | ST/意法 | |
| 型号/规格： | STS10N3LH5 | |
| 种类： | 绝缘栅(MOSFET) | |
| 沟道类型： | N沟道 | |
| 导电方式： | 增强型 | |
| 封装外形： | SMD(SO)/表面封装 | |
| 材料： | N-FET硅N沟道 | |
| 极间电容： | 35（pF） | |
| 漏极电流： | 11600（mA） | |
| 耗散功率： | 3600（mW） |
Features
Type VDSS RDS(on) max ID
STS10N3LH5 30 V 0.021 Ω 10 A
■ RDS(on) * Qg industry benchmark
■ Extremely low on-resistance RDS(on)
■ Very low switching gate charge
■ High avalanche ruggedness
■ Low gate drive power losses
Application
■ Switching applications
Description
This STripFET™V Power MOSFET technology is
among the latest improvements, which have been
especially tailored to achieve very low on-state
resistance providing also one of the best-in-class
FOM.
