SMD磁罩型功率电感WBD8D28L150N
| 价 格： | 0.01 | |
| 应用范围： | 滤波 | |
| 种类： | 电流互感器 | |
| 品牌/商标： | MOTTO/迈翔 | |
| 型号/规格： | WBD8D28L150N | |
| 封装形式： | 贴片电感 | |
| 绕线形式： | 单层密绕式 | |
| 导磁体性质： | 磁芯 | |
| 磁芯形状： | 柱形 | |
| 工作频率： | 低频 | |
| 安装方式： | 贴片式 | |
| 骨架材料： | 聚苯乙烯 | |
| 品质因数Q： | 0 | |
| 电感量： | 0（mH） | |
| 额定电流： | 0（mA） | |
| 分布电容： | 0（F） |
SMD磁罩型功率电感WBD8D28L150N
Motto WBD8D28L150N, Various high power inductors are superior to be high saturation for surface mounting.
Mainly used by power supply for VRT, OA equipment digital camera, LCD television set notebook PC, partable communication equipments, DC/DC converters, etc.
Part No | L (UH) | DCR(MΩ)MAX | IDCMAX(A) | Z TEST Freq(MHz) |
| 1.Inductance tested at 100KHZ,0.1V agilent / HP8753D network analyzer Packing; Reel size:16mm Quantity:1000pcs/Reel |
WBD8D28L1R0N | 1 | 11 | 6.5 | 1000 | ||
WBD8D28L2R5N | 2.5 | 15.6 | 4.5 | 1000 | ||
WBD8D28L3R3N | 3.3 | 18.2 | 4 | 1000 | ||
WBD8D28L4R7N | 4.7 | 24.7 | 3.4 | 1000 | ||
WBD8D28L7R3N | 7.3 | 39 | 2.8 | 1000 | ||
WBD8D28L100N | 10 | 47 | 2.5 | 1000 | ||
WBD8D28L150N | 15 | 69 | 1.9 | 1000 | ||
WBD8D28L220N | 22 | 99 | 1.6 | 1000 | ||
WBD8D28L330N | 33 | 156 | 1.3 | 1000 | ||
WBD8D28L470N | 47 | 195 | 1.15 | 1000 | ||
WBD8D28L680N | 68 | 286 | 0.92 | 1000 | ||
WBD8D28L101N | 100 | 430 | 0.75 | 1000 |
Special inquiries beside102s the above common used types can be met on your requirement.
