1.00mm排母系列连接器
| 价 格： | 0.10 | |
| 是否提供加工定制： | 否 | |
| 品牌/商标： | 国产 | |
| 型号/规格： | 1.00mm | |
| 应用范围： | 电脑 | |
| 种类： | 排针/排母/排线 | |
| 接口类型： | AC/DC |
1.00mm Female Header Single Row Bottom Ebrtt
Current Rating : 0.75AMP
Operation Temperature:-40°C to 105°C
Contact Resistance :30mΩ Max
Insulation Resistance :1000MΩ Min
Withstanding Voltage :AC 500V
Insulator Material :High Temperature
Thermoplastic(UL94V-0)
Contact Material :Phosphor Bronze
Contact plating :Au over 50 u″ Ni
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 王坚波
- 电话：0755-27483253
- 传真：0755-27483253
- 手机：
- QQ ：
USB 连接器
信息内容：IEEE 1394 4P/F SMT TYPE Electrical:Voltage-max[volts]:5VCurrent-max[amps]:0.5AContaoct Eesistance[ohms]:50m Ω maxDielectric Withstanding Voltage:100V ACInsulation Eresistance[ohms]:100MΩ min Mechanical:Moting:35N maxWithdrawal Force: 10N minDural ility:1500 cycles min Physical:Insulator:LCP UL 94V-0Contact:Phosphor BronzeMetal Shell:SpccCopper Flake:Capper AlloyPlating: Gold Flash/Gold 30umRemperature Range:-25°C to 85°C "
5-IN-1 Combo Connector
信息内容：Current Rating : 3AMPOperation Temperature :-40°C to 105°CContact Resistance :20mΩ MaxInsulation Resistance :1000MΩ MinWithstanding Voltage :AC 1000V Insulator Material :Polyester(UL94V-0) Standard:PBTContact Material :BrassContact plating :Au or Sn Over 50u″ Ni
