无锡固电ISC 供应D44C1三极管，iscsemi品牌
| 价 格： | 3.00 | |
| 是否提供加工定制： | 是 | |
| 品牌/商标： | iscsemi | |
| 型号/规格： | D44C1 | |
| 应用范围： | 放大 | |
| 材料： | 硅(Si) | |
| 极性： | NPN型 | |
| 击穿电压VCBO： | 30（V） | |
| 集电极允许电流ICM： | 4（A） | |
| 集电极耗散功率PCM： | 30（W） | |
| 截止频率fT： | 50（MHz） | |
| 结构： | 平面型 | |
| 封装形式： | 直插型 | |
| 封装材料： | 塑料封装 |
iscSilicon NPN Power Transistors
·Low Saturation Voltage
·Good Linearity of hFE
·Fast Switching Speeds
·Complement to Type D45C1
APPLICATIONS
·Designed for various specific and general purpose application
such as: output and driver stages of amplifiers operating at
frequencies from DC to greater than 1.0MHz series, shunt
and switching regulators; low and high frequency inverters/
converters and many others.
SYMBOL | PARAMETER | VALUE | UNIT |
VCES | Collector-Emitter Voltage | 40 | V |
VCEO | Collector-Emitter Voltage | 30 | V |
VEBO | Emitter-Base Voltage | 5 | V |
IC | Collector Current-Continuous | 4 | A |
ICM | Collector Current-Peak | 6 | A |
IB | Base Current-Continuous | 1 | A |
PC | Collector Power Dissipation @TC=25℃ | 30 | W |
Tj | Junction Temperature | 150 | ℃ |
Tstg | StorageTemperature Range | -55~150 | ℃ |
