仙童原装、15120、RHRP15120、TO-220AC、快恢复管
| 价 格： | 0.10 | |
| 是否提供加工定制： | 否 | |
| 产品类型： | 快恢复二极管 | |
| 是否进口： | 是 | |
| 品牌/商标： | FAIRCHILD/仙童 | |
| 型号/规格： | RHRP15120 | |
| 材料： | 硅(Si) | |
| 主要参数： | 15A 1200V | |
| 用途： | 开关电源 |
15A, 1200V Hyperfast Diode
The RHRP15120 is a hyperfast diode with soft recovery
characteristics (t
rr
< 65ns). It has half the recovery time of
ultrafast diodes and is of silicon nitride passivated
ion-implanted epitaxial planar construction.
This device is intended for use as a freewheeling/clamping
diode and rectifier in a variety of switching power supplies
and other power switching applications. Its low stored charge
and hyperfast soft recovery minimize ringing and electrical
noise in many power switching circuits, thus reducing power
loss in the switching transistors.
Formerly developmental type TA49098.
Symbol
Features
• Hyperfast with Soft Recovery. . . . . . . . . . . . . . . . . . <65ns
• Operating Temperature . . . . . . . . . . . . . . . . . . . . . . 175
o
C
• Reverse Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1200V
• Avalanche Energy Rated
• Planar Construction
Applications
• Switching Power Supplies
• Power Switching Circuits
• General Purpose
