贴片整流二极管 SM4007 DO-213AB
| 价 格： | 59.00 | |
| 是否提供加工定制： | 是 | |
| 产品类型： | 整流管 | |
| 是否进口： | 否 | |
| 品牌/商标： | PN | |
| 型号/规格： | SM4007 SM4005 SM4001 | |
| 材料： | 硅(Si) | |
| 主要参数： | IF=1A VB反向击穿电压大于1000V | |
| 用途： | 整流二极管 |
| SYMBOL | SM | UNITS | ||||||
4001 | 4002 | 4003 | 4004 | 4005 | 4006 | 4007 | |||
峰值反向电压 Maximum current Peak Reverse Voltage | VRRM | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | Volts |
反向有效电流 Maximum RMS Voltage | VRMS | 35 | 70 | 140 | 280 | 420 | 560 | 700 | Volts |
直流阻断电压 Maximum DC Blocking Voltage | VDC | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | Volts |
正向平均整流电流TT=60℃ Maximum Average Forward Rectified Current | I(AV) | 1.0 | Amps | ||||||
正向峰值浪涌电流 Peak Forward Surge Current, 8.3 ms Single Half Sine-wave Superimposed on Rated Load (JEDEC Method) | IFSM | 30 | Amps | ||||||
2.0A直流电时正向瞬间电压降 Maximum Instantaneous Forward Voltage @2.0A | VF | 1.1 | Volts | ||||||
反向漏电流 Maximum DC Reverse Current @ TA=25℃ at Rated DC Blocking Voltage @ TA=125℃ | IR | 5.0 100.0 | uA | ||||||
典型结电容 Typical Junction Capacitance ( Note 2 ) | CJ | 15 | pF | ||||||
工作温度存储温度 Operating AND Storage Temperature Range | TJ/TSTG | -55 to +150 | ℃ | ||||||
大量供应DO-213AB封装 SM4007 SM4006 SM4005 SM4004 SM4003 SM4002 SM4001 标准整流二极管。
- 所属城市：湖北
- [联系时请说明来自维库仪器仪表网]
- 联系人： 周慧
- 电话：8607124767777
- 传真：8607124777999
- 手机：
- QQ ：
肖特基二极管 SC310 SC32
信息内容：SYMBOLSC32SC33SC34SC35SC36SC38SC39SC310UNITS峰值反向电压Maximum current peak Reverse VoltageVRRM20304050608090100Volts反向有效电流Maximum RMS VoltageVRMS1421283542566471Volts直流阻断电压Maximum DC blocking VoltageVDC20304050608090100Volts正向平均整流电流 TL=75℃Maximum Average Forward Rectified CurrentI(AV)3.0Amps正向峰值浪涌电流Peak forward Surge Current single 8.3ms single half sine-wave superimposed on rated load (JEDEC Method)IFSM100Amps3.0A直流电时瞬间电压降 (NOTE 1)Maximum instantaneous Forward Voltageat3.0AVF0.500.750.85Volts反向漏电流Maximum DC Reverse Current TA=25℃at Rated DC Blocking Voltage TA=100℃IR0.520.0µA典型热阻 (NOTE2)Maximum Thermal ResistanceRθJLRθJA1775℃/W工作温度存储温度OperatingANDStorage Temperature RangeTJ/TSTG-50 to + 125/-50 to + 150℃
肖特基二极管 SR830 SR860 TO-220A
