HER高效整流二极管 HA2A HA2K
| 价 格： | 220.00 | |
| 是否提供加工定制： | 是 | |
| 产品类型： | 整流管 | |
| 是否进口： | 否 | |
| 品牌/商标： | PN | |
| 型号/规格： | HA2A HA2D HA2G HA2K | |
| 材料： | 硅(Si) | |
| 主要参数： | IF=2.0A VB大于800V | |
| 用途： | 整流二极管 |
| SYMBOL | HA2A | HA2B | HA2D | HA2G | HA2J | HA2K | UNITS | |
峰值反向电压 Maximum current Peak Reverse Voltage | VRRM | 50 | 100 | 200 | 400 | 600 | 800 | Volts | |
反向有效电流 Maximum RMS Voltage | VRMS | 35 | 70 | 140 | 280 | 420 | 560 | Volts | |
直流阻断电压 Maximum DC Blocking Voltage | VDC | 50 | 100 | 200 | 400 | 600 | 800 | Volts | |
正向平均整流电流TT=110℃ Maximum Average Forward Rectified Current | I(AV) | 2.0 | Amps | ||||||
正向峰值浪涌电流 Peak Forward Surge Current, 8.3 ms Single Half Sine-wave Superimposed on Rated Load (JEDEC Method) | IFSM | 50 | Amps | ||||||
2.0A直流电时正向瞬间电压降 Maximum Instantaneous Forward Voltage @ 2.0A | VF | 1.0 | 1.3 | 1.7 | Volts | ||||
反向漏电流 Maximum DC Reverse Current @ TA=25℃ at Rated DC Blocking Voltage @ TA=125℃ | IR | 5.0 200.0 | uA | ||||||
逆向恢复时间 Maximum Reverse Recovery Time ( Note 1 ) | Trr | 50 | 75 | nS | |||||
典型结电容 Typical Junction Capacitance ( Note 2 ) | CJ | 17.0 | pF | ||||||
典型热阻 Typical Thermal Resistance( Note 3) | RΘJL | 30.0 | ℃/W | ||||||
工作温度存储温度 Operating AND Storage Temperature Range | TJ/TSTG | -55 to +150 | ℃ | ||||||
