HER307 HER301 高效整流二极管 DO-27
| 价 格： | 200.00 | |
| 是否提供加工定制： | 是 | |
| 产品类型： | 整流管 | |
| 是否进口： | 否 | |
| 品牌/商标： | PN | |
| 型号/规格： | 高效整流管HER307 HER301 | |
| 材料： | 硅(Si) | |
| 主要参数： | IF=3.0A VB大于1000V | |
| 用途： | 高效整流二极管 |
| SYMBOL | HER | UNITS | |||||||||
301G | 302G | 303G | 304G | 305G | 306G | 307G | ||||||
峰值反向电压 MaximumCurrent PeakReverse Voltage | VRRM | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | Volts | |||
反向有效电压 Maximum RMS Voltage | VRMS | 35 | 70 | 140 | 280 | 420 | 560 | 700 | Volts | |||
直流阻断电压 Maximum DC Blocking Voltage | VDC | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | Volts | |||
正向平均整流电流TL=55℃ Maximum Average Forward Rectified Current
| I(AV) | 3.0 | Amps | |||||||||
正向峰值浪涌电流 Peak Forward Surge Current 8.3ms Single Sine-wave on Rated Load (JEDEC Method) | IFSM | 150.0 | Amps | |||||||||
3.0A直流电时正向瞬间电压降 Maximum Instantaneous Forward Voltage Drop at3.0A DC | VF | 1.0 | 1.3 | 1.7 | Volts | |||||||
反向漏电流 Maximum DC Reverse Current TA=25℃ at Rated DC Blocking Voltage TA=100℃ | IR | 10 200 | uA | |||||||||
典型热阻 Typical Thermal Resistance (NOTE 1) | RθJA RθJL | 35 10 | ℃/W | |||||||||
典型结节电容 Typical Junction Capacitance (NOTE 2) | CJ | 60 | 35 | pF | ||||||||
反向恢复时间 Maximum Reverse Recovery Time(NOTE 3) | Trr | 50 | 75 | ns | ||||||||
工作温度存储温度 Operating AND Storage Temperature Range | TSTG/TJ | -55 to +150 | ℃ | |||||||||
- 所属城市：湖北
- [联系时请说明来自维库仪器仪表网]
- 联系人： 周慧
- 电话：8607124767777
- 传真：8607124777999
- 手机：
- QQ ：
整流二极管 BOSCH PRESS-FIT 4352/4353
信息内容：提供BOSCH PRESS-FIT 各种规格整流二极管。 DIODE : BO PF 35A POS/NEG DIM(mm)：12.8 LEAD(mm)：1.28 SYMBOLPF-5 UNITS3505351352354356358 峰值反向电压Maximum current Peak Reverse VoltageVRRM50100200400600800Volts反向有效电流Maximum RMS VoltageVRMS3570140280420560Volts直流阻断电压Maximum DC Blocking VoltageVDC50100200400600800Volts正向平均整流电流TT=125℃Maximum Average Forward Rectified CurrentI(AV)35Amps正向峰值浪涌电流Peak Forward Surge Current, 8.3 ms Single Half Sine-wave Superimposed on Rated Load (JEDEC Method)IFSM400Amps35A直流电时正向瞬间电压降Maximum Instantaneous Forward Voltage @35AVF1.0Volts反向漏电流Maximum DC Reverse Current @ TA=25℃at Rated DC Blocking Voltage @ TA=125℃IR5.0500.0uA典型结电容Typical Junction CapacitanceCJ300pF典型热阻Typical Thermal ResistanceRΘJA1.0℃/W工作温度存储温度Operating AND Storage Temperature RangeTJ/TSTG-55 to +150℃
整流二极管 1N4007
信息内容：SYMBOL1N40011N40021N40031N40041N40051N40061N4007UNITS峰值反向电压MaximumCurrent PeakReverse VoltageVRRM501002004006008001000Volts反向有效电压Maximum RMS VoltageVRMS3570140280420560700Volts直流阻断电压Maximum DC Blocking VoltageVDC501002004006008001000Volts正向平均整流电流TA=50℃Maximum Average Forward Rectified current .375”(9.5mm) Lead LengthI(AV)1.0Amps正向峰值浪涌电流Peak Forward Surge Current,8.3ms Single Half Sine-wave Superimposed on Rated Load (JEDEC Method) TA=75℃IFSM30.0Amps1.0A直流电时瞬间电压降Maximum Instantaneous Forward Voltageat1.0AVF1.1Volts反向漏电压Maximum DC Reverse Current TA=25℃at Rated DC Blocking Voltage TA=125℃IR5.050.0uA典型热阻Typical Thermal ResistanceRθJARθJL5525℃/W典型结电容Typical Junction Capacitance (NOTE)CJ8Pf工作温度存储温度OperatingANDStorageTemperature RangeTJ/TSTG-65 to +150℃
