Miniature 12A 125VAC, 10A 250VAC/30VDC PCB Relay. UL/CUL, CSA, TUV, VDE approved. 450mW and 200mW coil are available. Optional for high CTI 250 plastic material (E version) and VDE approved type. Comply with RoHS-Directive 2011/65/EU.



307		□		□	-	1A		H	-	□	-	C		□
1		2		3		4		5		6		7		8

1.	307	--	Basic series designation
2.	Blank	--	Standard type
	H		High power type
3.	Blank	--	Standard type
	N	--	High sensitivity type
4.	1A	--	Single pole normally open
5.	C	--	Contact material AgNi
	H	--	Contact material AgSnO
6.	Blank	--	Standard type
	F	--	Class F
7.	C	--	Flux tight
	V	--	Sealed type
	S	--	Sealed type washable
8.	□	--	Coil voltage (please refer to the coil rating data for the availability)

外形(长×宽×高) mm		18.8 × 10.6 × 15.6
触点形式		1A
允许触点电流 (A)		8A
触点额定	阻性负载	307: 5A 240VAC ; 307H: 8A 240VAC, 10A 240VAC(※), 12A 125VAC(※)
线圈电压	DC	5 ~ 24V
	AC	------
额定功耗	DC	0.45W, 0.2W
	AC	------
预期寿命次数	机械 (Min.)	1×107
	电气 (Min.)	1×105, (※)3×104
介质耐压	开路触点间	1000VAC
	触点与线圈间	2500VAC
	触点组间	------
