10mm slim miniature PCB Power Relay. UL/CUL CSA/CUS TUV VDE approved. High CTI 250 material (VDE and E version). High sensitivity 200mW & 400mW. High surge voltage 8,000V between contacts and coil(1.2x50μs). Comply with RoHS-Directive 2011/65/EU

892		□		□	-	1AC	-	□	-	C		□		□
1		2		3		4		5		6		7		8

1.	892	--	Basic series designation
2.	Blank	--	Standard type
	H	--	High power type
3.	Blank	--	Standard type
	N	--	High sensitivity type
4.	1AC	--	Single pole normally open, Contact material AgNi
	1BC	--	Single pole normally closed, Contact material AgNi
	1CC	--	Single pole double throw, Contact material AgNi
	1AH	--	Single pole normally open, Contact material AgSnO
	1BH	--	Single pole normally closed, Contact material AgSnO
	1CH	--	Single pole double throw, Contact material AgSnO
5.	Blank	--	Standard type
	F	--	Class F
6.	C	--	Flux tight
	V	--	Sealed type
	S	--	Sealed type washable
7.	Blank	--	Standard type
	E	--	CTI 250V
8.	□	--	Coil voltage (please refer to the coil rating data for the availability)

外形(长×宽×高) mm		20 × 10.3 × 16
触点形式		1A, 1B, 1C
允许触点电流 (A)		7A
触点额定	阻性负载	892: NO/NC:5A/3A 240VAC, 892H: NO/NC:7A/5A 240VAC
线圈电压	DC	3 ~ 60V
	AC	------
额定功耗	DC	0.4W, 0.2W
	AC	------
预期寿命次数	机械 (Min.)	1×107
	电气 (Min.)	1×105
介质耐压	开路触点间	1000VAC
	触点与线圈间	4000VAC
	触点组间	------
