供应TI 的立体声音频音量控制集成电路PGA2310pa.ua
| 价 格： | 75.00 | |
| 型号/规格： | PGA2310pa.ua | |
| 品牌/商标： | TI (Texas Instruments德州仪器) |
TI 主页 > 半导体 > 音频 > 音量控制 > pga2310pa.pga2310ua
德州仪器的 +/-15V 立体声音频音量控制集成电路PGA2310PA PGA2310UA
PGA2310: Stereo Audio Volume Control
PGA2310依据封装不同，可以分为 PGA2310PA PGA2310UA
说明
The PGA2310 is a high-performance, stereo audio volume control designed for professional and high-end consumer audio systems. The ability to operate from ±15V analog power supplies enables the PGA2310 to process input signals with large voltage swings, thereby preserving the dynamic range available in the overall signal path. Using high performance operational amplifier stages internal to the PGA2310 yields low noise and distortion, while providing the capability to drive 600 loads directly without buffering. The three–wire serial control interface allows for connection to a wide variety of host controllers. In addition to support for daisy–chaining of multiple PGA2310 devices.
特性
DIGITALLY–CONTROLLED ANALOG VOLUME CONTROL
Two Independent Audio Channels
Serial Control Interface
Zero Crossing Detection
Mute Function
WIDE GAIN AND ATTENUATION RANGE
+31.5dB to –95.5dB with 0.5dB Steps
LOW NOISE AND DISTORTION
120dB Dynamic Range
0.0004% THD+N at 1kHz
LOW INTERCHANNEL CROSSTALK
–126dB
NOISE–FREE LEVEL TRANSITIONS
POWER SUPPLIES: ±15V Analog, +5V Digital
AVAILABLE IN DIP–16 AND SOL–16 PACKAGES
PIN AND SOFTWARE COMPATIBLE WITH THE PGA2311 AND CIRRUS LOGIC CS3310™
APPLICATIONS 应用
AUDIO AMPLIFIERS
MIXING CONSOLES
MULTI–TRACK RECORDERS
BROADCAST STUDIO EQUIPMENT
音频放大器
调音台
多轨录音机
广播演播室设备
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 杜先生 吕先生
- 电话：755-83995200/36952200/36952211
- 传真：755-83995200
- 手机：13713594500/13510097856
- QQ ：
供应TI 的高速14位模数转换器集成电路ADS62P48IRGCT
